IXFT120N25X3HV IXFQ120N25X3
IXFH120N25X3
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max
gfs
VDS = 10V, ID = 60A, Note 1
Gate Input Resistance
54
90
S
RGi
1.6
Ciss
Coss
Crss
7870
1260
2
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
Effective Output Capacitance
Co(er)
Co(tr)
500
pF
pF
Energy related
Time related
VGS = 0V
DS = 0.8 • VDSS
1900
V
td(on)
tr
td(off)
tf
29
32
ns
ns
ns
ns
Resistive Switching Times
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
V
100
12
RG = 5 (External)
Qg(on)
Qgs
122
40
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
34
RthJC
RthCS
0.26 C/W
C/W
TO-247& TO-3P
0.21
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max
IS
VGS = 0V
120
A
A
ISM
VSD
Repetitive, pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
480
1.4
V
trr
QRM
IRM
140
880
12.6
ns
IF = 60A, -di/dt = 100A/μs
nC
VR = 100V
A
Note 1. Pulse test, t 300s, duty cycle, d 2%.
