4N38X, 4N38AX
4N38, 4N38A
OPTICALLY COUPLED
ISOLATOR
PHOTOTRANSISTOR OUTPUT
APPROVALS
Dimensions in mm
2.54
l
l
ULrecognised,FileNo.E91231
1
6
5
4
'X'SPECIFICATIONAPPROVALS
VDE 0884 in 3 available lead form : -
- STD
7.0
6.0
2
3
- G form
1.2
3.0
-SMDapprovedtoCECC00802
CertifiedtoEN60950bythefollowing
Test Bodies :-
Nemko-CertificateNo.P01102464
Fimko-CertificateNo.FI18166
Semko-ReferenceNo.0202037/01-22
Demko-CertificateNo.311158-01
BSIapproved-CetificateNo. 8001
l
7.62
6.62
7.62
0.26
4.0
3.0
13°
Max
0.5
3.35
0.5
l
DESCRIPTION
The 4N38, 4N38A series of optically coupled
ABSOLUTE MAXIMUM RATINGS
(25°C unless otherwise specified)
isolators consist of infrared light emitting diode
and NPN silicon photo transistor in a standard
6 pin dual in line plastic package.
Storage Temperature
Operating Temperature
-55°C to + 150°C
-55°C to + 100°C
FEATURES
Lead Soldering Temperature
(1/16 inch (1.6mm) from case for 10 secs) 260°C
l
Options :-
10mm lead spread - add G after part no.
Surface mount - add SM after part no.
Tape&reel - add SMT&R after part no.
High BVCEO (80V min)
High Isolation Voltage (5.3kV ,7.5kVPK
All electrical parameters 100R%MStested
Custom electrical selections available
INPUT DIODE
l
l
l
l
Forward Current
Reverse Voltage
Power Dissipation
60mA
6V
105mW
)
APPLICATIONS
l
l
l
l
DC motor controllers
Industrial systems controllers
Measuring instruments
Signal transmission between systems of
different potentials and impedances
OUTPUT TRANSISTOR
Collector-emitter Voltage BVCEO
Collector-base Voltage BVCBO
Emitter-collector Voltage BVECO
Power Dissipation
80V
80V
6V
160mW
OPTION G
OPTION SM
SURFACEMOUNT
7.62
POWER DISSIPATION
Total Power Dissipation
(derate linearly 2.67mW/°C above 25°C)
200mW
0.6
0.1
1.25
0.75
0.26
10.46
9.86
10.16
ISOCOM COMPONENTS LTD
Unit 25B, Park View Road West,
Park View Industrial Estate, Brenda Road
Hartlepool, Cleveland, TS25 1YD
Tel: (01429) 863609 Fax :(01429) 863581
27/2/03
DB90047m-AAS/A2
