DWM2F90N060
Apr. 2006
Ultra-Fast Soft Recovery Diode Module
Description
Equivalent Circuit and Package
Ultra-FRD module devices are optimized to reduce losses
and EMI/RFI in high frequency power conditioning electrical systems.
These diode modules are ideally suited for power converters,
motors drives and other applications where switching losses
are significant portion of the total losses.
Features
☞ Repetitive Reverse Voltage : VRRM = 600V
☞ Low Forward Voltage Drop : VF(typ.) = 1.4V
☞ Average Forward Current : IF(AV.) = 90A @ Tc = 100℃
☞ Ultra-Fast Reverse Recovery Time : trr(typ.) = 100 ns
☞ Extensive Characterization of Recovery Parameters
☞ Reduced EMI and RFI
Package : SOT-227
☞ Isolation Type Package
Applications
Motor Drives, Free wheel use, High Power Converters, Welders,
Various Switching and Telecommunication Power Supply.
E301932
Please see the package Out line information
Absolute Maximum Ratings @ Tj=25℃(Per Leg)
Symbol
Parameter
Conditions
Ratings
Unit
VRRM
VR(DC)
IF(AV)
Repetitive Peak Reverse Voltage
Reverse DC Voltage
600
480
180
90
V
V
A
A
A
Average Forward Current
@ Tc = 25℃
@ Tc = 100℃
Resistive Load
IFSM
Surge(non-repetitive) Forward
Current
I2t for Fusing
One Half Cycle at 60Hz,
Peak Value
Value for One Cycle Current,
tw = 8.3ms, Tj = 25℃ Start
1300
I2
7.1* 103
2s
A
t
Tj
Junction Temperature
Storage Temperature
Isolation Voltage
Maximum Power Dissipation
Mounting Torque
Terminal Torque
-40 ~ 150
-40 ~ 125
2500
250
1.45
℃
℃
V
Tstg
Visol
Pd
-
-
-
@ AC 1 minutes
W
N.m
N.m
g
1.45
30
Weight
Typical Including Screws
