AntennaDuplexers(SeriesY/C)
Antenna Duplexers (SMD)
Series:Y, C
Type:
M
R
C
L
(TX: 4 Poles, RX: 5 Poles)
(TX: 3 Poles, RX: 4 Poles)
(TX: 3 Poles, RX: 3 Poles)
(TX: 1 Pole,s RX: 2 Poles)
Surface Mounting Antenna Duplexers, ÒSeries YÓ and
ÒSeries CÓ consisting of two different dielectric filter
units for a transmitter and a receiver, are designed for
applications in portable cellular telephones.
■
Features (as an example of EZFC836R881G)
● Miniture type SMD (1.2 ml: 23 × 14 × 4 mm max.)
● Wide product range for analog/digital portable cellular
telephones
● Designed for reflow soldering
■
Recommended Applications
● Portable Cellular telephones (AMPS, E á ETACS,
GSM, NTT, N á TACS, PDC 800 MHz, PCN, PCS)
■
Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
Z
F
C
Product Code
Series
Low-Channel
Type
High-Channel
Design No.
Center Frequency
Center Frequency
Design and Specifications are subject to change without notice. Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety issues arises from this product, please inform us immediately for technical consultation.
