AZ9371
SENSITIVE
SUBMINIATURE RELAY
FEATURES
• Ambient Temperature up to 105°C (221°F)
• Thin vertical profile, only 7 mm wide
• High sensitivity, 113 mW pickup
• Dielectric strength 4000 Vrms
• > 5,5 mm clearance and creepage
• 5 Amp switching capability (version “T” 10 Amp)
• Two different footprints available
• Reinforced insulation (VDE 0700, 0631)
• UL, CUR file E44211
GENERAL DATA
• VDE certificate 40030746
Life Expectancy
Mechanical
Minimum operations
5 million operations
CONTACTS
Arrangement SPST (1 Form A)
Standard version
Ratings
Resistive load:
Electrical
1 x 105 at 5 A, 250 VAC res. [1]
5 x 104 at 5 A, 250 VAC res. [2]
Max. switched power: 150 W or 1385 VA
(Version “T”: 300 W or 2770 VA)
Max. switched current: 5 A
(Version “T”: 10 A)
Max. switched voltage: 30 VDC* or 277 VAC
High capacity version “T”
Electrical
5 x 105 at 7 A, 250 VAC res. [1]
1 x 104 at 10 A, 250 VAC res. [1][2]
6 x 104 at 7 A, 250 VAC res. [2]
* Note: If switching voltage is greater than 30 VDC,
special precautions must be taken.
Please contact the factory.
Operate Time (typical)
Release Time (typical)
6 ms at nominal coil voltage
Rated Load
UL
3 ms at nominal coil voltage
(with no coil suppression)
See chart for UL contact ratings on page 2.
VDE
3A (51A) at 250VAC, capacitive, 85°C, 10k cycles [2]*
Dielectric Strength
4000 Vrms coil to contact
(at sea level for 1 min.) 1000 Vrms between open contacts
Standard version
5 A at 250 VAC, resistive, 85°C, 50k cycles [1][2]
5 A at 30 VDC, resistive, 85°C, 30k cycles [1][2]
4 A at 250 VAC. cos phi 0.4, 70°C, 100k cycles [1]
Surge Voltage
Coil to contact
10,000 V (at 1.2x50 µs)
Insulation
Resistance
1000 megohms min. at 20°C, 500 VDC,
50% RH
High capacity version “T”
10 A at 250 VAC, resistive, 85°C, 10k cycles [1][2]
10 A at 30 VDC, resistive, 85°C, 10k cycles [1][2]
7 A at 250 VAC, resistive, 105°C, 50k cycles [1]
7 A at 250 VAC, resistive, 85°C, 50k cycles [2]
7 A at 30 VDC, resistive, 105°C, 50k cycles [1]
7 A at 30 VDC, resistive, 85°C, 50k cycles [2]
Dropout
Greater than 5% of nominal coil voltage
Ambient Temperature
Operating
At nominal coil voltage
-40°C (-40°F) to 105°C (221°F)
Vibration
0.062" (1.5 mm) DA at 10–55 Hz
10 g
Shock
* duty factor: 2 seconds on / 15 seconds off
Enclosure
P.B.T. polyester
Tinned copper alloy, P.C.
270°C (518°F)
5 seconds
Material
Silver nickel [1], silver tin oxide [2],
gold plating available
Terminals
Max. Solder Temp.
Max. Solder Time
Max. Solvent Temp.
Max. Immersion Time
Weight
Resistance
< 100 milliohms initially
(at 6 V, 1 A, voltage drop method)
80°C (176°F)
COIL
30 seconds
Power
3 grams
At Pickup Voltage
(typical)
113 mW
NOTES
Max. Continuous
Dissipation
750 mW at 20°C (68°F) ambient
1. All values at 20°C (68°F)
2. Relay may pull in with less than “Must Operate” value.
3. Mounting position “terminals upside” is not recommended, if an
electrical or mechanical life of > 100,000 operations is required.
4. Specifications subject to change without notice.
Temperature Rise
Temperature
26°C (47°F) at nominal coil voltage
Max. 155°C (311°F) Class F
