Supply voltage limits
Output voltage
Switching capacity in mA
Switching frequency
Voltage drop
20...264 V AC
<= 250 V AC
3 A (cos φ = 1 for 0.5 million cycles at 1 operating cycle per second at 250 V)
<= 20 Hz
<= 1.5 V (closed state)
Current consumption
Power consumption in W
Time delay range
Delay first up
35 mA (no-load)
2 W
0...15 s monostable, on-delay or off-delay (programmable) delay
<= 60 ms
Delay response
Delay recovery
Setting-up
<= 25 ms
<= 25 ms
Sensitivity adjustment with potentiometer
Electrical durability
Depth
500000 cycles, switching capacity: 3000 mA, cos φ = 1, 60 cyc/mn at 250 V
1.73 in (44 mm)
3.9 in (99 mm)
Height
Width
1.77 in (45 mm)
0.62 lb(US) (0.28 kg)
Product weight
Kit composition
Sensor
Reflector XUZC50
Environment
Product certifications
CE
CSA
UL
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
-13...131 °F (-25...55 °C)
-40...158 °F (-40...70 °C)
7 gn (f = 10...55 Hz) conforming to IEC 60068-2-6
20 gn (duration = 11 ms) conforming to IEC 60068-2-27
IP67 conforming to IEC 60529
Shock resistance
IP degree of protection
NEMA degree of protection
NEMA 12 conforming to IEC 60529
NEMA 13 conforming to IEC 60529
NEMA 3 conforming to IEC 60529
NEMA 4 conforming to IEC 60529
NEMA 4X conforming to IEC 60529
NEMA 6 conforming to IEC 60529
NEMA 6P conforming to IEC 60529
Ordering and shipping details
Category
22481 - SENSORS, PHOTOELECTRIC
Discount Schedule
GTIN
DS2
003389110881776
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
1
0.93000000000000005
N
Country of origin
FR
Offer Sustainability
RoHS (date code: YYWW)
Will be compliant on 3Q2013
Will be compliant on 3Q2013
Contractual warranty
Warranty period
18 months
