Current consumption
Maximum switching current
Voltage drop
60 mA
100 mA with overload and short-circuit protection
<= 1 V
Switching frequency
Delay response
Delay recovery
Marking
40 Hz
5 ms
1000 ms
CE
Height
0.71 in (18 mm)
0.71 in (18 mm)
0.71 in (18 mm)
2.91 in (73.91 mm)
0.71 in (18 mm)
0.71 in (18 mm)
0.71 in (18 mm)
0.24 lb(US) (0.11 kg)
Width
Depth
Length
CAD overall height
CAD overall width
CAD overall depth
Product weight
Environment
Standards
IEC 60947-5-2
Product certifications
UL
NEMA degree of protection
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
NEMA 4X indoor use only
32...140 °F (0...60 °C)
-40...212 °F (-40...100 °C)
+/-1 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
30 gn 11 ms (in all 3 axes) conforming to IEC 60068-2-27
8 kV, level 4 conforming to IEC 61000-4-2
9.14 V/yd (10 V/m), level 3 conforming to IEC 61000-4-3
1 kV, level 3 conforming to IEC 61000-4-4
Shock resistance
Resistance to electrostatic discharge
Resistance to electromagnetic fields
Resistance to fast transients
Ordering and shipping details
Category
22490 - SENSORS-ULTRASONIC (XX5,6)
Discount Schedule
GTIN
DS2
003389119129190
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
1
0.11
Y
Country of origin
US
Offer Sustainability
California proposition 65
- - - - - - - Substance 1
- - - - - - - Substance 2
WARNING: This product can expose you to chemicals including:
Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and
Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other
reproductive harm.
- - - - - - - More information
For more information go to www.p65warnings.ca.gov
Contractual warranty
Warranty period
18 months
