0RQB-D0W15LG

型号：

0RQB-D0W15LG

品牌：

BEL[ BEL FUSE INC. ]

页数：

19 页

PDF大小：

920 K

下载PDF手册
0RQB-D0W15L
Isolated DC-DC Converter
The 0RQB-D0W15L is an isolated DC/DC converter that provide up
to 200 W of output power from a wide input range (72 V, 96 V and 110
V typical).
The unit is designed to be highly efficient. Standard feature include
remote on/off, input under-voltage lockout, over current and short
circuit protection and overvoltage protection. Conformal coated PCB
is used for environmental ruggedness.
Key Features & Benefits
72/96/110 VDC Input / 15 VDC @ 13.3 A Output/1/4th Brick Converter
Isolated
Fixed Frequency
High Efficiency
Input Under Voltage Lockout
Input Over Voltage Lockout
OCP/SCP
Output Over-Voltage Protection
Over Temperature Protection
•
•
•
•
•
•
•
•
•
•
•
Approved to UL/CSA60950-1, 2nd +A2 version (TBD)
Class II, Category 2, Isolated DC/DC Converter (refer to IPC-9592B)
Applications
Industrial
Railways
Telecommunications
•
•
•
belfuse.com/power-solutions
2
0RQB-D0W15L
1. MODEL SELECTION
MODEL
NUMBER
OUTPUT
VOLTAGE
INPUT
VOLTAGE
MAX. OUTPUT
CURRENT
MAX. OUTPUT
POWER
TYPICAL
EFFICIENCY
0RQB-D0W15L
15 VDC
72/96/110V VDC
13.3 A
200 W
92%
NOTE: Add “G” suffix at the end of the model number to indicate Tray Packaging.
PART NUMBER EXPLANATION
0
R
QB
-
D0
W
15
L
G
RoHS
Status
Series
Name
DOSA
Quarter
Brick
Output
Power
Output
Voltage
Mounting Type
Input Range
Active Logic
Package Type
RoHS
6
L – Active Low, with
Through hole mount
200 W
72/96/110 V
15 V
G – Tray package
baseplate
2. ABSOLUTE MAXIMUM RATINGS
PARAMETER
DESCRIPTION
MIN
-0.5
-0.3
0
TYP
MAX
164
18
UNITS
Continuous non-operating Input Voltage
Remote On/Off
-
-
-
-
V
V
Current Sink
10
mA
V
Isolation voltage
Input to output
-
2250
Temperature measured at the center of the
baseplate, full load
Operating Temperature
-40
-
95
C
Storage Temperature
Altitude
-55
-
-
-
125
C
2000
m
NOTE: Ratings used beyond the maximum ratings may cause a reliability degradation of the converter or may permanently damage the
device.
tech.support@psbel.com
belfuse.com/power-solutions
3
0RQB-D0W15L
3. INPUT SPECIFICATIONS
All specifications are typical at 25°C unless otherwise stated.
PARAMETER
DESCRIPTION
MIN
TYP
MAX
UNIT
Operating Input Voltage 1
Fully functioning for long term operation.
50
43
-
-
137.5
50
V
V
Fully functioning for 100ms operation.
Full function is not guaranteed but undamaged
for 1s operation.
Operating Input Voltage 2
137.5
156
V
Input Current (full load)
-
-
-
5.7
100
5
A
mA
mA
mA
mA
V
Input Current (no load)
50
2
Remoted Off Input Current
-
Input Reflected Ripple Current (rms)
Input Reflected Ripple Current (pk-pk)
Under-voltage Turn on Threshold
Under-voltage Turn off Threshold
Over-voltage Shutdown Threshold
Over-voltage Recovery Threshold
-
20
50
47
41
163
155
-
-
-
Turn on Threshold
46
40
161
154
49
42.5
165
156
Turn off Threshold, non-latching
Auto-recovery and non-latching.
V
V
V
4. OUTPUT SPECIFICATIONS
All specifications are typical at nominal input, full load at 25°C unless otherwise stated.
PARAMETER
DESCRIPTION
MIN
TYP
MAX
UNIT
Test condition of the output setpoint:
Vin=110V, Io=100% load at 25°C ambient.
Output Voltage Set Point
14.7
15
15.3
V
Load Regulation
-
-
±30
±30
±200
250
50
mV
mV
mV
mV
mV
A
Line Regulation
-
-
Regulation Over Temperature
Ripple and Noise (pk-pk)
Ripple and Noise (rms)
Output Current Range
Output DC Current Limit
Rise time
-
±60
40KHz-100MHz BW, with 1µF ceramic
capacitor and 220uF bulk electrolytic at
output.
-
-
-
-
0
-
13.3
17
Enter a hiccup mode, non-latching.
14
16
-
A
Vin=110V, Io=13.3A, with 1µF ceramic
capacitor and 220uF bulk electrolytic at
output.
-
200
500
3
ms
ms
%
Start-up time
-
300
0
Overshoot at Turn on
Undershoot at Turn off
Output Capacitance
Transient Response
50% load to 75% Load
Settling Time
-
-
0
3
%
220
-
5000
uF
-
-
-
-
-
-
-
-
600
2
mV
ms
mV
ms
di/dt=0.1A/us, with 1µF ceramic capacitor
and 220uF bulk electrolytic at output.
75% load to 50% Load
Settling Time
600
2
North America
Asia-Pacific
Europe, Middle East
+1 408 785 5200
+86 755 298 85888
+353 61 225 977
© 2019 Bel Power Solutions & Protection
Rev. AC
4
0RQB-D0W15L
5. GENERAL SPECIFICATIONS
PARAMETER
Io=60% Irate – 100% Irate
Io=40% Irate - 60% Irate
DESCRIPTION
MIN
91
TYP
92
MAX
UNIT
%
-
Efficiency
TA = 25°C
89
91
-
-
%
Switching Frequency
-
250
-
kHz
V
Output Voltage Trim Range
13.5
16.5
Temperature measured at the center of the
baseplate, full load
Over Temperature Protection
-
110
-
℃
Output Over Voltage Protection
Enter a latching. non-hiccup mode
-
-
-
-
-
17.5
V
Weight
FIT
69
-
-
-
g
-
Calculated Per Bell Core SR-332 (Vin=110
V, Vo=15V, Io=10.67A, Ta = 25°C,
FIT=109/MTBF)
190.48
5.25
MTBF
Mhrs
Dimensions
Inches (L × W × H)
Millimeters (L × W × H)
2.45 x 1.45x 0.59
62.24 x 36.84 x15
Inches
Millimeters
Isolation Characteristics
Input to Output
-
-
2250
2250
2250
-
Vdc
Vdc
Vdc
Ohm
pF
Input to Heatsink
-
-
Output to Heatsink
Isolation Resistance
Isolation Capacitance
-
10M
-
-
-
2200
-
6. EFFICIENCY DATA
95.00%
90.00%
85.00%
80.00%
75.00%
70.00%
65.00%
60.00%
55.00%
50.00%
Vin:50V
Vin:110V
Vin:137.5V
0.6 1.3 2.7 4.0 5.3 6.6 8.0 9.3 10.7 12.0 13.3
OUTPUT CURRENT(A)
Figure 1. Efficiency data
tech.support@psbel.com
belfuse.com/power-solutions
5
0RQB-D0W15L
7. RIPPLE AND NOISE
Figure 2. Ripple and noise waveform
Note: Ripple and noise 96Vdc input, 15Vdc/13.3A output and Ta=25 deg C, and with a 1uF ceramic cap and 220uF electrolytic cap at
output.
North America
Asia-Pacific
Europe, Middle East
+1 408 785 5200
+86 755 298 85888
+353 61 225 977
© 2019 Bel Power Solutions & Protection
Rev. AC
6
0RQB-D0W15L
8. THERMAL DERATING CURVES
1. In order to make it convenient for safety and test engineer, each curve has 3 air velocity at most. It is better that the middle one is
at the centre of minimum and maximum. For example, 0-200-400, 0-100-200, 100-200-300.
2. If the minimum air velocity is 0LFM or 50LFM, do not mark on the curve, just record as "Natural Convection".
Maximum junction temperature of semiconductors derated to 115 degree C.
Figure 3. Thermal test setup
TA is the temperature on the large heatsink rib.
Figure 4. Derating curve
tech.support@psbel.com
belfuse.com/power-solutions
7
0RQB-D0W15L
9. TRANSIENT RESPONSE
Transient Response: di/dt=0.1A/us, 1uF ceramic cap and 220uF electrolytic cap at output.
Figure 5.
CH1:Vout
CH2:Iout
Vout= 15V 50%-75% Load Transients at Vin=96V, Ta=25 deg C
Figure 6.
CH1:Vout
CH2:Iout
Vout= 15V 75%-50% Load Transients at Vin=96V, Ta=25 deg C
Note: Transient Response at Vin=96V, di/dt=0.1A/µS, 1µF ceramic cap and 220µF AL. cap at output, Ta=25℃
North America
Asia-Pacific
Europe, Middle East
+1 408 785 5200
+86 755 298 85888
+353 61 225 977
© 2019 Bel Power Solutions & Protection
Rev. AC
8
0RQB-D0W15L
10. STARTUP&SHUTDOWN
Rise time
Figure 7. Vout= 15V/13.3A @Vin=96V,Ta=25℃
Figure 8. Vout= 15V/13.3A @Vin=96V,Ta=25℃ , Cext =5000uF
Startup time
Figure 9.
Figure10.
Startup from Vin
Ch1: Vo
Startup from ON/OFF
Ch1: Vo
Ch3: Vin
Ch3: ON/OFF
Vout= 15V/13.3A @Vin=96V,Ta=25℃
Vout= 15V/13.3A @Vin=96V,Ta=25℃
tech.support@psbel.com
belfuse.com/power-solutions
9
0RQB-D0W15L
STARTUP&SHUTDOWN(CONTINUED)
Shutdown
Figure 11. Vout= 15V/13.3A @Vin=96V,Ta=25℃
Figure 12. Vout= 15V/13.3A @ Vin=96V,Ta=25℃, Cext = 5000uF
North America
Asia-Pacific
Europe, Middle East
+1 408 785 5200
+86 755 298 85888
+353 61 225 977
© 2019 Bel Power Solutions & Protection
Rev. AC
10
0RQB-D0W15L
11. REMOTE ON/OFF
PARAMETER
DESCRIPTION
MIN
-0.3
2.4
TYP
MAX
0.8
UNIT
Signal Low (Unit On)
-
-
V
V
Active Low
Remote On/Off pin is open, the module is off
Signal High (Unit Off)
Current Sink
18
0
-
1
mA
Recommended remote on/off circuit for active low
Vin+
On/off
Vin-
Vin+
On/off
Vin-
Figure 13. Control with open collector/drain circuit
Figure 14. Control with photocoupler circuit
Vin+
Vin+
Vcc
On/off
On/off
Vin-
Vin-
Figure 15. Control with logic circuit
Figure 16. Permanently on
tech.support@psbel.com
belfuse.com/power-solutions
11
0RQB-D0W15L
12. REMOTE SENSE
This module has remote sense compensation feature. It can minimizes the effects of resistance between moudle's output and load
in system layout and facilitates accurate voltage regulation at load terminals or other selected point.
1. The remote sense lines carries very little current and hence do not require a large cross-sectional area.
2. This module compensates for a maximum drop of 4% of the nominal output voltage.
3. If the unit is already trimmed up, the available remote sense compensation range should be correspondingly reduced. The total
voltage increased by trim and remote sense should not exceed 4% of the nominal output voltage.
4. When using remote sense compensation, all the resistance, parasitic inductance and capacitance of the system are incorpotated
within the feedback loop of this module. The can make an effect on the module's compensation, affecting the stability and dyn.
5. Recommend the connection of remote sense compensation as below figure. There are a resistor RS+ (100 ohm) from Vo+ to
Sense+ and a resistor RS- (100 ohm)) from Vo- to Sense- inside of this module.
Vo+
Sense+
Load
Sense-
Vo-
Figure 17.
6. If not using remote sense compensation, please connect sense directly to output at module's pin, that is, connect sense+ to Vo+
and sense- to Vo- at module's pin, the shorter the better. See below figure.
Vo+
Sense+
Load
Sense-
Vo-
Figure 18.
North America
Asia-Pacific
Europe, Middle East
+1 408 785 5200
+86 755 298 85888
+353 61 225 977
© 2019 Bel Power Solutions & Protection
Rev. AC
12
0RQB-D0W15L
13. OVER CURRENT PROTECTION
To provide protection in a fault output overload condition, the module is equipped with internal current-limiting circuitry and can
endure current limiting for a few mili-seconds. If the overcurrent condition persists beyond a few milliseconds, the module will shut
down into hiccup mode and restart once every 800mS. The module operates normally when the output current goes into specified
range. The typical average output current is 0.020A during hiccup.
Figure 19. Over current protection
tech.support@psbel.com
belfuse.com/power-solutions
13
0RQB-D0W15L
14. OVER TEMPERATURE PROTECTION
Temperature sensor
115 ℃ MAX
TOP VIEW
Figure 20. Over temperature protection
15. INPUT UNDER-VOLTAGE LOCKOUT
Under-voltage Lockout
Voltage Falling
Voltage Rising
Input Voltage (V)
V1
V2
Figure 21. Input under-voltage lockout
V1=38V
V2=40V
North America
Asia-Pacific
Europe, Middle East
+1 408 785 5200
+86 755 298 85888
+353 61 225 977
© 2019 Bel Power Solutions & Protection
Rev. AC
14
0RQB-D0W15L
16. SAFETY&EMC
Safety:
1. Compliance to UL/CSA60950-1
2. Compliance to EN/IEC60950-1
EMC:
Setup:
Figure 22.
CX1
0.22uF
RY11
RY12
CY11
CY12
T1A
1mH
-
-
RY22
0R
-
-
CY21
CY22
T2A
CX2
RY21
0R
-
-
-
-
-
0.22uF
2200pF
CY31
2200pF
CY32
CX3
RY31
-
RY32
-
100uF/200V AL *2
CX4
-
-
CY41
CY42
RY41
-
RY42
-
220uF AL
-
-
tech.support@psbel.com
belfuse.com/power-solutions
15
0RQB-D0W15L
SAFETY&EMC(CONTINUED)
Positive:
Figure 23.
Negative:
Figure 24.
North America
+1 408 785 5200
Asia-Pacific
+86 755 298 85888
Europe, Middle East
+353 61 225 977
© 2019 Bel Power Solutions & Protection
Rev. AC
16
0RQB-D0W15L
17. TRIM
0RQB-D0W15L Trim Resistor Calculate
Trim down test circuit
Vout
Trim
GND
Module
Rtrimdown
Figure 25. Trim down test circuit
푉푂_푟푒푞
[ ]
− 1 퐾훺
푅푡푟푖푚푑표푤푛
=
15 − 푉푂_푟푒푞
Trim up test circuit
Vout
Rtrimup
Module
Trim
GND
Figure 26. Trim up test circuit
1 − 0.08267
푅푡푟푖푚푢푝
=
− 1
0.08267 − 1.24/푉푂_푟푒푞
Note: Vo_req=Desired(trimmed) output voltage[V].
tech.support@psbel.com
belfuse.com/power-solutions
17
0RQB-D0W15L
18. MECHANICAL DIMENSIONS
OUTLINE
Figure 27. Outline
Note: This module is recommended and compatible with Pb-Free Wave Soldering and must be soldered using a peak solder temperature of
no more than 260 ºC for less than 5 seconds.
NOTES:
1）All Pins: Material - Copper Alloy;
Finish – Tin plated.
2）Undimensioned components are shown for visual reference only.
3）All dimensions in inches; Tolerances: x.xx +/-0.02 in [0.50 mm]. x.xxx +/-0.010 in [0.25 mm].
North America
Asia-Pacific
Europe, Middle East
+1 408 785 5200
+86 755 298 85888
+353 61 225 977
© 2019 Bel Power Solutions & Protection
Rev. AC
18
0RQB-D0W15L
MECHANICAL DIMENSIONS(CONTINUED)
PIN DEFINITIONS
Figure 28. Pin
PIN
1
FUNCTION
Vin (+)
PIN
5
FUNCTION
Sense(-)
Trim
2
On/off
6
3
Vin (-)
7
Sense(+)
Vout(+)
4
Vout(-)
8
RECOMMENDED PAD LAYOUT
Figure 29. Recommended pad layout
tech.support@psbel.com
belfuse.com/power-solutions
19
0RQB-D0W15L
19. REVISION HISTORY
DATE
REVISION
CHANGES DETAIL
APPROVAL
S.Wang
S.Wang
F.Tao
2018-10-09
2019-03-13
2019-06-18
AA
AB
AC
First release
Second release, Update Safety&EMC circuit parameters, no load current
Update mechanical outline. Add model photo. Add EMC waveforms.
For more information on these products consult: tech.support@psbel.com
NUCLEAR AND MEDICAL APPLICATIONS - Products are not designed or intended for use as critical components in life support systems,
equipment used in hazardous environments, or nuclear control systems.
TECHNICAL REVISIONS - The appearance of products, including safety agency certifications pictured on labels, may change depending on the
date manufactured. Specifications are subject to change without notice.
North America
Asia-Pacific
Europe, Middle East
+1 408 785 5200
+86 755 298 85888
+353 61 225 977
© 2019 Bel Power Solutions & Protection
Rev. AC
厂商 型号 描述 页数 下载

BEL

 		0RQ1-C5TV80 隔离式DC / DC转换器[ ISOLATED DC/DC CONVERTERS ] 17 页

BEL

 		0RQ1-C5TV8A 隔离式DC / DC转换器[ ISOLATED DC/DC CONVERTERS ] 17 页

BEL

 		0RQ1-C5TV8B 隔离式DC / DC转换器[ ISOLATED DC/DC CONVERTERS ] 17 页

BEL

 		0RQ1-C5TV8L 隔离式DC / DC转换器[ ISOLATED DC/DC CONVERTERS ] 17 页

BEL

 		0RQ1-C5TV8X 隔离式DC / DC转换器[ ISOLATED DC/DC CONVERTERS ] 17 页

BEL

 		0RQ1-C5TV8_11 隔离式DC / DC转换器[ ISOLATED DC/DC CONVERTERS ] 17 页

BEL

 		0RQ1-Q0T12 隔离式DC / DC转换器[ ISOLATED DC/DC CONVERTERS ] 14 页

BEL

 		0RQ1-Q0T120 隔离式DC / DC转换器[ ISOLATED DC/DC CONVERTERS ] 14 页

BEL

 		0RQ1-Q0T12L 隔离式DC / DC转换器[ ISOLATED DC/DC CONVERTERS ] 14 页

BEL

 		0RQ1-T0S12BG [ DC-DC Regulated Power Supply Module, ] 11 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.198076s
