Common mode Noise Filters with ESD Suppressor
Common mode Noise Filters
with ESD Suppressor
Type: EXC24CS
Features
●
Provides EMI Filtering and ESD Potection (L 1.25 mm×W 1.00 mm×H 0.50 mm)
ESD and noise suppression of high-speed differential transmission lines with little influence of
●
waveform rounding on signal transmission
●
High Common mode attenuation in the range between 700 MHz and 1 GHz (RF band)
Strong multilayer/sintered structure, excellent reflow resistance and high mounting reliability
Lead, halogen and antimony-free
RoHS compliant
●
●
●
Recommended Applications
●
Smartphones, Tablet PCs and DSC
ESD and noise suppression of high-speed differential data lines such as MIPI and USB
●
Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
X
C
2
4
C
S
9
0
0
U
Product Code
Size
Number of Type Characteristics
Terminals
Nominal Impedance
Form
Suffix
Coupled
type
Intergrated
ESD Protection
The first two digits are
significant figure of
impedance value, and the
third one denotes the
Code Dimensions(mm)
Code
Packing
4 Terminals
C
S
Noise Filter
Embossed Carrier Taping
4 mm pitch, 5,000 pcs.
1.25 × 1.00 × 0.50
U
2
(L) × (W) × (H)
number of zeros following
Construction
Dimensions in mm (not to scale)
E
F
G
Ferrite
Ceramics
C
D
A
B
Mass
Dimensions (mm)
Part No.
(inch size)
(Weight)
[mg/pc.]
Inner Conductor
A
B
C
D
E
F
G
Ceramics
EXC24CS
(0504)
1.25 0.15 1.00 0.15 0.50 0.10 0.20 0.15 0.55 0.10 0.30 0.10 0.20 0.10
2.4
Circuit Configuration (No Polarity)
6
5
6
5
1
4
GND 1
4 GND
●
The pin numbers shown here are for reference
purposes only. Confirm the actual pin number
arrangement with the exchanged specification
documents.
2
3
2
3
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
00 Apr. 2015
