MYGTR01205BZN Short Form
1
DC-DC Converter Short Form
MYGTR01205BZN (Small Size & High Efficiency)
■ FEATURES
・ High efficiency & Small Size SIL
・ Wide input rage (17V to 40V)
・ Adjustable output voltage ( 5.0V or 8.5V or 12.0V )
・ Plastic case type
・ ON/OFF control function
・ Short circuit protection
■ GENERAL SPECIFICATIONS (Ta=25ºC)
Item
Symbol
Condition
MIN.
17.0
TYP.
24.0
MAX.
40.0
UNIT
V
Input Voltage
Vin
R1=0Ω
Vout1
Vout2
Vout3
Iout1
Iout2
Iout3
11.64
8.245
4.85
0.0
12.00
12.36
8.755
5.15
3.0
Iout=0~3A
R1=1kΩ
Output Voltage
Output Current
Vin=17.0~40.0V
Vin=17.0~40.0V
8.500
V
A
Iout=0~4A
R1=Open
Iout=0~5.2A
R1=0Ω
5.00
-
-
-
Vout=12Vtyp.
R1=1kΩ
0.0
4.0
Vout=8.5Vtyp.
R1=Open
Vout=5Vtyp.
0.0
5.2
Vin=24V,
Iout=5.2A,Vout=5V
BW=20MHz
Ripple Voltage
Efficiency
Vrpl
EFF
-
100
-
mVpp
%
Vin=24V, Iout=5.2A, Vout=5V
-
93
-
-
-
OFF
2.5
-
Remote Voltage
On/Off
Vin=17.0~40.0V
ON
V
A
-
0.5
Protection Output
Current
Iocp
SCP
Vin=17.0~40.0V
5.6
-
-
If output is shorted to GND, DC-DC Converter shall be operated in a
hiccup mode. After the short circuit event has cleared, the output is
automatically brought back into regulation.
Short Circuit
Protection
Note:
1. This datasheet is downloaded from the website of Murata Manufacturing co., ltd. Therefore, it’ s specifications are subject to change or our
products in it may be discontinued without advance notice. Please check with our sales representatives or product engineers before ordering.
2. This datasheet has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product
specifications or transact the approval sheet for product specifications before ordering.
