TYPE NX 7.0x5.0 SEAM SEALED CRYSTAL CLOCK OSCILLATOR
VER. A
29-Dec-14
NX7031E0125.000000
ELECTRICAL SPECIFICATIONS
SRe Part Number :
NX7031E0125.000000
Item
Symbol
Specifications
Units
Notes
Nominal Frequency
Fo
FT
125.000000
± 50
MHz
Frequency Stability
ppm **See note
Operating Temperature Range
Supply Voltage
TR
VCC
LT
-40 to +85
+3.3 ± 5.0%
LVDS
°C
V
Logic Type
I
CC/OE
Supply Current, Output Enabled
Supply Current, Output Disabled
Duty Cycle (Symmetry)
Rise / Fall Time
70
mA
mA
%
Max.
Max.
I
CC/OD
40
DC/SY
TR/TF
VOL
45 / 55
400
Measured 50% of Waveform
Max. measured 20/80% of Waveform
Typ / Min.
ps
V
Output Voltage "0" Level
Output Voltage "1" Level
Output Load
1.10 / 0.9
1.43 / 1.6
VOH
V
Typ / Max.
Output requires termination
Min. / Max.
100Ω connected between outputs
VOD
RMS
Differential Output Voltage
Jitter, Phase
247 / 454
0.4 / 0.6
6
mV
ps
ps
ps
°C
Typ./Max. 12KHz ~ 20MHz Frequency Band
Max. 20,000 Consecutive Periods
Max. 100,000 Random Periods
Jitter, Accumulated
RMS(1-σ)
Pk-Pk
Jitter, Peak to Peak
Storage Temperature Range
40
-55 to +125
※ This product doesn't include harmful substance that stipulated by SONY SS-00259 Level 1 and S-AT2-001 Level 1 standard. RoHS Compliant (Pb - Free).
**Stability includes all combinations of Operating Temperature, Load changes, rated Input (Supply) Voltage changes, Initial
Calibration Tolerance (25°C), Aging (1 years at 25°C Average Effective Ambient Temperature), Shock and Vibration.
Output Enable / Disable Function
Parameter
Input Voltage (Pin1), Output Enable
Input Voltage (Pin1), Output Disable (low power standby)
Output Disable Delay
Min.
Typ.
Max.
Notes
Units
V
0.7VCC
Or Open
Output is Hi-Z
0.3VCC
100
V
ns
Output Enable Delay
100
ns
Start Up Time
10
ms
E0-R-4-014 Rev. E
Page 1
