W
Vishay Dale
NTC Thermistors, Surface Mount Chip
FEATURES
• Top and bottom surface terminations.
• High-density monolithic ceramic construction.
• Allows design flexibility for use with hybrid circuitry.
• Model W is a thermistor die with silver conductors fired on the
top and bottom surfaces. The bottom surface can be reflow
soldered or conductive epoxied directly to a substrate bonding
pad and the top surface wire bonded to complete the circuit
connection.
STANDARD ELECTRICAL SPECIFICATIONS AND DIMENSIONS in inches [millimeters]
± 10%, ± 5% R25 Tolerance
T
L
W
R25
PART
CURVE
T
(Ohms)
NUMBER
NUMBER
L
W
(Nominal)
10.0M
500,000
250,000
200,000
100,000
100,000
100,000
80,000
50,000
50,000
30,000
30,000
30,000
20,000
15,000
10,000
3000
2000
2000
1000
1000
500
500
300
50
12W1004
12W5003
12W2503
7W2003
12W1003
8W1003
7W1003
8W8002
8W5002
7W5002
8W3002
7W3002
1W3002
1W2002
1W1502
1W1002
1W3001
1W2001
2W2001
2W1001
1W1001
2W5000
1W5000
2W3000
2W0500
12
12
12
7
12
8
7
8
8
7
8
7
1
1
1
1
1
1
0.043 ± 0.004 [10.1 ± 0.10]
0.053 ± 0.004 [10.4 ± 0.10]
0.075 ± 0.006 [10.9 ± 0.15]
0.041 ± 0.004 [10.0 ± 0.10]
0.119 ± 0.008 [30.0 ± 0.20]
0.049 ± 0.004 [10.2 ± 0.10]
0.054 ± 0.005 [10.4 ± 0.13]
0.049 ± 0.004 [10.2 ± 0.10]
0.053 ± 0.004 [10.4 ± 0.10]
0.051 ± 0.004 [10.3 ± 0.10]
0.072 ± 0.005 [10.8 ± 0.13]
0.069 ± 0.005 [10.8 ± 0.13]
0.029 ± 0.003 [0.74 ± 0.08]
0.035 ± 0.004 [0.89 ± 0.10]
0.041 ± 0.004 [10.0 ± 0.10]
0.050 ± 0.005 [10.3 ± 0.13]
0.068 ± 0.005 [10.7 ± 0.13]
0.101 ± 0.006 [20.6 ± 0.15]
0.049 ± 0.004 [10.2 ± 0.10]
0.053 ± 0.004 [10.4 ± 0.10]
0.105 ± 0.006 [20.7 ± 0.15]
0.060 ± 0.005 [10.5 ± 0.13]
0.148 ± 0.006 [30.8 ± 0.15]
0.077 ± 0.006 [20.0 ± 0.15]
0.188 ± 0.012 [40.8 ± 0.31]
0.043 ± 0.004 [10.1 ± 0.10]
0.053 ± 0.004 [10.4 ± 0.10]
0.075 ± 0.006 [10.9 ± 0.15]
0.041 ± 0.004 [10.0 ± 0.10]
0.119 ± 0.008 [30.0 ± 0.20]
0.049 ± 0.004 [10.2 ± 0.10]
0.054 ± 0.005 [10.4 ± 0.13]
0.049 ± 0.004 [10.2 ± 0.10]
0.053 ± 0.004 [10.4 ± 0.10]
0.051 ± 0.004 [10.3 ± 0.10]
0.054 ± 0.005 [10.4 ± 0.13]
0.069 ± 0.005 [10.8 ± 0.13]
0.029 ± 0.003 [0.74 ± 0.08]
0.035 ± 0.004 [0.89 ± 0.10]
0.041 ± 0.004 [10.0 ± 0.10]
0.050 ± 0.005 [10.3 ± 0.13]
0.054 ± 0.004 [10.4 ± 0.10]
0.054 ± 0.004 [10.4 ± 0.10]
0.049 ± 0.004 [10.2 ± 0.10]
0.053 ± 0.004 [10.4 ± 0.10]
0.105 ± 0.006 [20.7 ± 0.15]
0.060 ± 0.005 [10.5 ± 0.13]
0.148 ± 0.006 [30.8 ± 0.15]
0.077 ± 0.006 [20.0 ± 0.15]
0.188 ± 0.012 [40.8 ± 0.31]
0.020 [0.51]
0.016 [0.41]
0.016 [0.41]
0.033 [0.84]
0.016 [0.41]
0.029 [0.74]
0.029 [0.74]
0.024 [0.61]
0.018 [0.46]
0.014 [0.36]
0.015 [0.38]
0.015 [0.38]
0.032 [0.81]
0.032 [0.81]
0.032 [0.81]
0.032 [0.81]
0.015 [0.38]
0.015 [0.38]
0.037 [0.94]
0.022 [0.56]
0.015 [0.38]
0.015 [0.38]
0.015 [0.38]
0.015 [0.38]
0.015 [0.38]
2
2
1
2
1
2
2
ORDERING INFORMATION
8
W
8002
K
CURVE NUMBER
MODEL
RESISTANCE VALUE
TOLERANCE @ + 25°C
K = ± 10%
J = ± 5%
First three digits are significant. The last digit
is the multiplier. (80,000 ohms is illustrated.)
Document Number 33006
Revision 04-Sep-01
