Advanced Technical Information
IXA 40PG1200DHGLB
IC25
VCES
VCE(sat) typ = 1.85V
= 63A
=1200V
XPT IGBT phaseleg
ISOPLUS™
Surface Mount Power Device
7
D3
D4
6
1
D1
D2
S1
4
5
9
S2
3
2
E72873
8
Features
IGBTs S1, S2
• XPT IGBT
- low saturation voltage
- positive temperature coefficient for
easy paralleling
- fast switching
- short tail current for optimized
performance in resonant circuits
• SonicTM diode
- fast reverse recovery
- low operating forward voltage
- low leakage current
• VCEsat detection diode
- integrated into package
- very fast diode
Symbol
VCES
Conditions
Maximum Ratings
TVJ = 25°C to 150°C
1200
20
V
VGES
V
IC25
IC80
TC = 25°C
TC = 80°C
63
45
A
A
ICM
VCEK
VGE = 15 V; RG = 27 W; TVJ = 125°C
RBSOA, clamped inductive load; L = 100 µH
105
VCES
A
µs
W
tSC
VCE = 900 V; VGE = 15 V; RG = 27 W; TVJ = 125°C
10
(SCSOA) none repetitive
Ptot
TVJ = 25°C
230
• Package
Symbol
Conditions
Characteristic
Values
- isolated back surface
- low coupling capacity between pins
and heatsink
(TVJ = 25°C, unless otherwise specified)
- PCB space saving
min. typ. max.
- enlarged creepage towards heatsink
- application friendly pinout
- low inductive current path
- high reliability
VCE(sat)
IC = 35 A; VGE = 15 V; TVJ = 25°C
TVJ = 125°C
1.85
2.2
2.15
V
V
VGE(th)
ICES
IC = 1.5 mA; VGE = VCE
5.4
6.5
V
VCE = VCES; VGE = 0 V; TVJ = 25°C
TVJ = 125°C
0.15
mA
mA
Applications
0.25
• Phaseleg
- buck-boost chopper
IGES
VCE = 0 V; VGE
=
20 V
200
nA
td(on)
tr
td(off)
tf
Eon
Eoff
70
40
250
100
3.8
4.1
ns
ns
ns
ns
mJ
mJ
• Full bridge
- power supplies
- induction heating
- four quadrant DC drives
- controlled rectifier
• Three phase bridge
- AC drives
Inductive load; TVJ = 125°C
VCE = 600 V; IC = 35 A
VGE = 15 V; RG = 27 W
Cies
QGon
VCE = 25 V; VGE = 0 V; f = 1 MHz
VCE = 600 V; VGE = 15 V; IC = 35 A
tbd
107
pF
nC
- controlled rectifier
RthJC
RthJH
0.55 K/W
0.95 K/W
with heatsink compound (IXYS test setup)
0.75
IXYS reserves the right to change limits, test conditions and dimensions.
© 2011 IXYS All rights reserved
20110616a
1 - 3
