XTR103
XTR103
XTR103
4-20mA Current Transmitter with
RTD EXCITATION AND LINEARIZATION
FEATURES
APPLICATIONS
● LESS THAN ±1% TOTAL ADJUSTED
ERROR, –40°C TO +85°C
● INDUSTRIAL PROCESS CONTROL
● FACTORY AUTOMATION
● SCADA
● RTD EXCITATION AND LINEARIZATION
● TWO OR THREE-WIRE RTD OPERATION
● WIDE SUPPLY RANGE: 9V to 40V
● HIGH PSR: 110dB min
Pt100 NONLINEARITY CORRECTION
● HIGH CMR: 80dB min
USING XTR103
5
4
DESCRIPTION
The XTR103 is a monolithic 4-20mA, two-wire
current transmitter designed for Platinum RTD tem-
perature sensors. It provides complete RTD current
excitation, instrumentation amplifier, linearization, and
current output circuitry on a single integrated circuit.
3
Uncorrected
RTD Nonlinearity
2
Corrected
Nonlinearity
1
0
Versatile linearization circuitry provides a 2nd-order
correction to the RTD, typically achieving a 40:1
improvement in linearity.
–1
–200°C
+850°C
Instrumentation amplifier gain can be configured for a
wide range of temperature measurements. Total
adjusted error of the complete current transmitter,
including the linearized RTD is less than ±1% over the
full –40 to +85°C operating temperature range. This
includes zero drift, span drift and nonlinearity. The
XTR103 operates on loop power supply voltages down
to 9V.
Process Temperature (°C)
IR = 0.8mA
IR = 0.8mA
9 to 40V
+
VPS
The XTR103 is available in 16-pin plastic DIP and
SOL-16 surface-mount packages specified for the
–40°C to +85°C temperature range.
4-20 mA
VO
XTR103
RG
RL
RTD
–
RLIN
International Airport Industrial Park
•
Mailing Address: PO Box 11400, Tucson, AZ 85734
FAXLine: (800) 548-6133 (US/Canada Only)
•
Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706
•
Tel: (520) 746-1111 • Twx: 910-952-1111
Internet: http://www.burr-brown.com/
•
•
Cable: BBRCORP
•
Telex: 066-6491
•
FAX: (520) 889-1510
•
Immediate Product Info: (800) 548-6132
©1992 Burr-Brown Corporation
PDS-1145E
Printed in U.S.A. October, 1993
SBOS017
SPECIFICATIONS
ELECTRICAL
At TA = +25°C, V+ = 24V, and 2N6121 external transistor, unless otherwise noted.
XTR103BP/BU
TYP
XTR103AP/AU
TYP
PARAMETER
CONDITIONS
MIN
MAX
MIN
MAX
UNITS
OUTPUT
Output Current Equation
Total Adjusted Error(1)
Output Current, Specified Range
Over-Scale Limit
Under Scale-Limit
Full Scale Output Error
Noise: 0.1Hz to 1kHz
IO = VIN • (0.016 + 40/RG) + 4mA, VIN in Volts, RG in Ω
A
% of FS
mA
mA
mA
TMIN to TMAX
±1
20
±2
4
✻
✻
✻
✻
34
3.6
±15
8
40
3.8
±50
✻
✻
✻
✻
VIN = 1V, RG = ∞
±100
µA
µAp-p
R
G = 40Ω
ZERO OUTPUT(2)
Initial Error
vs Temperature
vs Supply Voltage, V+
vs Common-Mode Voltage
VIN = 0, RG = ∞
4
±5
±0.2
0.5
0.1
✻
✻
✻
✻
✻
mA
µA
µA/°C
µA/V
µA/V
±50
±0.5
2
±100
±1
✻
V+ = 9V to 40V(3)
VCM = 2V to 4V(3)
2
✻
SPAN
Span Equation (Transconductance)
Untrimmed Error
vs Temperature(4)
Nonlinearity: Ideal Input
RTD Input
S = 0.016 + 40/RG
✻
✻
✻
A/V
%
ppm/°C
%
RG ≥ 75Ω
±0.1
±1
✻
±100
✻
±20
±50
0.01
Pt100: –200°C to +850°C
RLIN = 1127Ω
0.1
✻
%
INPUT
Differential Range
Input Voltage Range(3)
Common-Mode Rejection
Impedance: Differential
Common-Mode
RG = ∞
1
4
✻
✻
V
V
dB
GΩ
GΩ
mV
µV/°C
dB
2
80
✻
✻
VIN = 2V to 4V(3)
100
3
0.5
±0.5
±1
130
100
0.1
2
✻
✻
✻
✻
±2
✻
✻
✻
✻
✻
Offset Voltage
vs Temperature
±2.5
±2.5
✻
±5
vs Supply Voltage, V+
Input Bias Current
vs Temperature
Input Offset Current
vs Temperature
V+ = 9V to 40V(3)
110
✻
250
2
20
✻
✻
✻
✻
nA
nA/°C
nA
0.01
0.25
nA/°C
CURRENT SOURCES(5)
Current
Accuracy
vs Temperature
vs Power Supply, V+
Compliance Voltage(3)
Matching
vs Temperature
vs Power Supply, V+
0.8
±0.25
±25
50
✻
✻
±50
✻
mA
%
ppm/°C
ppm/V
V
%
ppm/°C
ppm/V
±0.5
±50
±1
±100
V+ = 9V to 40V(3)
V+ = 9V to 40V(3)
(V–IN) – 0.2
(V+) – 5
±0.5
±25
✻
✻
✻
✻
±50
±10
10
✻
✻
POWER SUPPLY
Voltage Range(3), V+
9
40
✻
V
TEMPERATURE RANGE
Specification, TMIN to TMAX
Operating
–40
–40
85
125
✻
✻
✻
✻
°C
°C
θJA
80
✻
°C/W
✻ Specification same as XTR103BP.
NOTES: (1) Includes corrected Pt100 nonlinearity for process measurement spans greater than 100°C, and over-temperature zero and span effects. Does not include
initial offset and gain errors which are normally trimmed to zero at 25°C. (2) Describes accuracy of the 4mA low-scale offset current. Does not include input amplifier
effects. Can be trimmed to zero. (3) Voltage measured with respect to IO pin. (4) Does not include TCR of gain-setting resistor, RG. (5) Measured with RLIN = ∞ to
disable linearization feature.
®
XTR103
2
PIN CONFIGURATION
ABSOLUTE MAXIMUM RATINGS
Power Supply, V+ (referenced to IO pin) .......................................... 40V
Input Voltage, V+ , V– (referenced to IO pin) ........................ 0V to V+
TOP VIEW
IN
IN
Storage Temperature Range ........................................ –55°C to +125°C
Lead Temperature (soldering, 10s) .............................................. +300°C
Output Current Limit ............................................................... Continuous
Junction Temperature ................................................................... +165°C
1
2
3
4
5
6
7
8
Zero Adjust
16 Zero Adjust
15 B (Base)
14 EINT (Internal Emitter)
13 IR2
Zero Adjust
VI–N
VI+N
RG
RG
IO
ELECTROSTATIC
DISCHARGE SENSITIVITY
This integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.
12 IR1
11 E (Emitter)
10 V+
RLIN
9
RLIN
ESD damage can range from subtle performance degradation
to complete device failure. Precision integrated circuits may
be more susceptible to damage because very small parametric
changes could cause the device not to meet its published
specifications.
PACKAGE/ORDERING INFORMATION
PACKAGE
DRAWING TEMPERATURE
PRODUCT
PACKAGE
NUMBER(1)
RANGE
XTR103AP
XTR103BP
XTR103AU
XTR103BU
16-pin Plastic DIP
16-pin Plastic DIP
SOL-16 Surface Mount
SOL-16 Surface Mount
180
180
211
211
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
NOTE: (1) For detailed drawing and dimension table, please see end of data
sheet, or Appendix C of Burr-Brown IC Data Book.
The information provided herein is believed to be reliable; however, BURR-BROWN assumes no responsibility for inaccuracies or omissions. BURR-BROWN assumes
no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject to change
without notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. BURR-BROWN does not authorize or warrant
any BURR-BROWN product for use in life support devices and/or systems.
®
3
XTR103
TYPICAL PERFORMANCE CURVES
At TA = +25°C, V+ = 24VDC, unless otherwise noted.
TRANSCONDUCTANCE vs FREQUENCY
80
STEP RESPONSE
60
40
RG = 25Ω
RS = ∞
20mA
4mA
RG = 100Ω
RG = 400Ω
RS = 25Ω
RG = 2kΩ
20
0
RG = ∞
100µs/Div
100
0.1
0
1k
10k
100k
1M
100k
50
Frequency (Hz)
COMMON-MODE REJECTION
vs FREQUENCY (RTI)
POWER SUPPLY
REJECTION vs FREQUENCY (RTI)
120
100
80
140
120
100
80
G = 0.16A/V
(RG = 400Ω)
G = 0.16A/V
(RG = 400Ω)
60
60
40
40
20
0
20
0
1
10
100
1k
10k
0.1
1
10
100
1k
10k
100k
Frequency (Hz)
Frequency (Hz)
LOOP RESISTANCE vs LOOP POWER SUPPLY
INPUT OFFSET VOLTAGE vs LOOP POWER SUPPLY
60
50
40
30
20
1750
1500
1250
1000
750
1550Ω
Span = ∆IO = 16mA
Without external transistor
(V+) – 9V
RL max =
20mA
Ω
L = 100
R
Ω
L = 600
R
Operating
Region
Ω
L = 1k
500
R
With external transistor
10
0
250
0
9V
R
L = 1kΩ
RL = 600Ω
RL = 100Ω
10
20
30
40
10
20
30
40
Loop Power Supply Voltage, VPS (V)
Loop Power Supply Voltage, VPS (V)
®
XTR103
4
TYPICAL PERFORMANCE CURVES (CONT)
At TA = +25°C, +V = 24VDC, unless otherwise noted.
INPUT CURRENT NOISE DENSITY vs FREQUENCY
OUTPUT CURRENT NOISE DENSITY vs FREQUENCY
10
10
RG = ∞
1
1
0.1
0.1
0.1
1
10
100
1k
10k
100k
0.1
1
10
100
Frequency (Hz)
1k
10k
100k
Frequency (Hz)
INPUT VOLTAGE NOISE DENSITY vs FREQUENCY
1k
100
10
0.1
1
10
100
1k
10k
100k
Frequency (Hz)
®
5
XTR103
Negative input voltage, VIN, will cause the output current to
be less than 4mA. Increasingly negative VIN will cause the
output current to limit at approximately 3.6mA.
APPLICATION INFORMATION
Figure 1 shows the basic connection diagram for the XTR103.
The loop power supply, VPS provides power for all circuitry.
Output loop current is measured as a voltage across the
series load resistor, RL.
Increasingly positive input voltage (greater than VFS) will
produce increasing output current according to the transfer
function, up to the output current limit of approximately
34mA.
Two matched 0.8mA current sources drive the RTD and
zero-setting resistor, RZ. The instrumentation amplifier in-
put of the XTR103 measures the voltage difference between
the RTD and RZ. The value of RZ is chosen to be equal to
the resistance of the RTD at the low-scale (minimum)
measurement temperature. RZ can be adjusted to achieve
4mA output at the minimum measurement temperature to
correct for input offset voltage and reference current mis-
match of the XTR103.
EXTERNAL TRANSISTOR
Transistor Q1 conducts the majority of the signal-dependent
4-20mA loop current. Using an external transistor isolates
the majority of the power dissipation from the precision
input and reference circuitry of the XTR103, maintaining
excellent accuracy.
Since the external transistor is inside a feedback loop its
RCM provides an additional voltage drop to bias the inputs of
the XTR103 within their common-mode range. Resistor, RG,
sets the gain of the instrumentation amplifier according to
the desired temperature measurement range.
characteristics are not critical. Requirements are: VCEO
=
45V min, β = 40 min and PD = 800mW. Power dissipation
requirements may be lower if the loop power supply voltage
is less than 40V. Some possible choices for Q1 are listed in
Figure 1.
The transfer function through the complete instrumentation
amplifier and voltage-to-current converter is:
The XTR103 can be operated without this external transistor
by connecting pin 11 to 14 (see Figure 2). Accuracy will be
somewhat degraded by the additional internal power dissipa-
tion. This effect is most pronounced when the input stage is
set for high gain (for low full-scale input voltage). The
typical performance curve “Input Offset Voltage vs Loop
Supply Voltage” describes this behavior.
IO = VIN • (0.016 + 40/RG) + 4mA,
(VIN in volts, RG in ohms, RLIN = ∞)
where VIN is the differential input voltage. With no RG
connected (RG = ∞), a 0V to 1V input produces a 4-20mA
output current. With RG = 25Ω, a 0V to 10mV input pro-
duces a 4-20mA output current. Other values for RG can be
calculated according to the desired full-scale input voltage,
VFS, with the formula in Figure 1.
VIN = V+IN – V–
IN
Possible choices for Q1 (see text).
= IR (RTD – RZ)
TYPE
PACKAGE
2N4922
TIP29B
TIP31B
TO-225
TO-220
TO-220
13
12
IR
4
V+
IR
IN
10
V+
5
RG
4-20 mA
IR
0.8mA
=
IR
0.8mA
=
+
VIN
–
15
11
(2, 3)
RG
B
E
Q1
0.01µF
XTR103
+
RL
–
+
6
3
RG
V–
VPS
–
IO
RLIN
IN
7
9
RLIN
8
40
RG
IO = 4mA + VIN (0.016 +
)
(3)
RLIN
(1, 3)
RTD
RZ
NOTES: (1) RZ = RTD resistance at the minimum measured temperature.
2500
RCM = 1.5kΩ
, where VFS is Full Scale VIN.
(2)
RG
=
Ω
1
– 1
VFS
0.01µF
(3)
See Table I for values.
FIGURE 1. Basic RTD Temperature Measurement Circuit.
®
XTR103
6
The low operating voltage (9V) of the XTR103 allows
operation directly from personal computer power supplies
(12V ±5%). When used with the RCV420 Current Loop
Receiver (Figure 8), load resistor voltage drop is limited to
1.5V.
10
V+
LINEARIZATION
11
14
E
On-chip linearization circuitry creates a signal-dependent
variation in the two matching current sources. Both current
sources are varied equally according to the following equa-
XTR103
0.01µF
EINT
tion:
500 • VIN
IR1 = IR2 = 0.8 +
IO
RLIN
7
(IR in mA, VIN in volts, RLIN in ohms)
(maximum IR = 1.0mA)
For operation without external
transistor, connect pin 11 to
pin 14. See text for discussion
of performance.
This varying excitation provides a 2nd-order term to the
transfer function (including the RTD) which can correct the
RTD’s nonlinearity. The correction is controlled by resistor
RLIN which is chosen according to the desired temperature
measurement range. Table I provides the RG, RZ and RLIN
resistor values for a Pt100 RTD.
FIGURE 2. Operation Without External Transistor.
LOOP POWER SUPPLY
The voltage applied to the XTR103, V+, is measured with
respect to the IO connection, pin 7. V+ can range from 9V to
40V. The loop supply voltage, VPS, will differ from the
voltage applied to the XTR103 according to the voltage drop
on the current sensing resistor, RL (plus any other voltage
drop in the line).
If no linearity correction is desired, do not connect a resistor
to the RLIN pins (RLIN = ∞). This will cause the excitation
current sources to remain a constant 0.8mA.
ADJUSTING INITIAL ERRORS
Most applications will require adjustment of initial errors.
Offset errors can be corrected by adjustment of the zero
resistor, RZ.
If a low loop supply voltage is used, RL must be made a
relatively low value to assure that V+ remains 9V or greater
for the maximum loop current of 20mA. It may, in fact, be
prudent to design for V+ equal or greater than 9V with loop
currents up to 34mA to allow for out-of-range input condi-
tions. The typical performance curve “Loop Resistance vs
Loop Power Supply” shows the allowable sense resistor
values for full-scale 20mA.
Figure 3 shows another way to adjust zero errors using the
output current adjustment pins of the XTR103. This provides
a minimum of ±300µA (typically ±500µA) adjustment around
the initial low-scale output current. This is an output current
adjustment which is independent of the input stage gain set
MEASUREMENT TEMPERATURE SPAN ∆T (°C)
100°C 200°C 300°C 400°C 500°C 600°C 700°C 800°C 900°C 1000°C
TMIN
–200°C
18/90
653
18/185 18/286 18/396 18/515 18/645 18/788 18/946 18/1120 18/1317
838
996
1087
1131
1152
1159
1158
1154
1140
–100°C
0°C
60/84
1105
60/173 60/270 60/374 60/487 60/610 60/746 60/895 60/1061
1229
1251
1249
1231
1207
1181
1155
1128
100/81 100/167 100/260 100/361 100/469 100/588 100/718 100/860
1287 1258 1229 1201 1173 1145 1117 1089
100°C
200°C
300°C
400°C
500°C
600°C
700°C
800°C
138/78 138/162 138/252 138/349 138/453 138/567 138/691
1211 1183 1155 1127 1100 1073 1046
RZ /RG
RLIN
(Values are in Ω.)
175/76 175/157 175/244 175/337 175/437 175/546
1137 1110 1083 1056 1030 1003
212/73 212/152 212/235 212/325 212/422
1066
247/71 247/146 247/227 247/313
996 971 946 921
280/68 280/141 280/219
930 905 881
313/66 313/136
1039
1013
987
962
NOTE: Values shown are for a Pt100 RTD.
Double (x2) all values for Pt200.
865
841
345/64
803
375/61
743
TABLE I. RZ, RG, and RLIN Resistor Values for Pt100 RTD.
®
7
XTR103
Figure 4, shows a three-wire RTD connection for improved
accuracy with remotely located RTDs. RZ’s current is routed
through a third wire to the RTD. Assuming line resistance is
equal in RTD lines 1 and 2, this produces a small common-
mode voltage which is rejected by the XTR103.
(a)
XTR103
16
2
OPEN-CIRCUIT DETECTION
1
10kΩ
±500µA typical
output current
adjustment range.
The optional transistor Q2 in Figure 4 provides predictable
behavior with open-circuit RTD connections. It assures that
if any one of the three RTD connections is broken, the
XTR103’s output current will go to either its high current
limit (≈34mA) or low current limit (≈3.6mA). This is easily
detected as an out-of-range condition.
(b)
XTR103
16
REVERSE-VOLTAGE PROTECTION
2
1
Figure 5 shows two ways to protect against reversed output
connection lines. Trade-offs in an application will determine
which technique is better. D1 offers series protection, but
causes a 0.7V loss in loop supply voltage. This may be
undesirable if V+ can approach the 9V limit. Using D2
(without D1) has no voltage loss, but high current will flow
in the loop supply if the leads are reversed. This could
damage the power supply or the sense resistor, RL. A diode
with a higher current rating is needed for D2 to withstand the
highest current that could occur with reversed lines.
5kΩ
5kΩ
±50µA typical
output current
adjustment range.
FIGURE 3. Low-Scale Output Current Adjustment.
with RG. If the input stage is set for high gain (as required
with narrow temperature measurement spans) the output
current adjustment may not provide sufficient range. In these
cases, offset can be nulled by adjusting the value of RZ.
SURGE PROTECTION
TWO-WIRE AND
Long lines are subject to voltage surges which can damage
semiconductor components. To avoid damage, the maxi-
mum applied voltage rating for the XTR103 is 40V. A zener
diode may be used for D2 (Figure 6) to clamp the voltage
applied to the XTR103 to a safe level. The loop power
supply voltage must be lower than the voltage rating of the
zener diode.
THREE-WIRE RTD CONNECTIONS
In Figure 1, the RTD can be located remotely simply by
extending the two connections to the RTD. With this two-
wire connection to the RTD, line resistance will introduce
error. This error can be partially corrected by adjusting the
values of RZ, RG, and RLIN
.
Equal line resistances here creates
a small common-mode voltage
which is rejected by XTR103.
13
12
IR
4
V+
IR
IN
10
V+
(RLINE
)
RZ
5
RG
Q1
1
2
0.01µF
RTD
RG
XTR103
15
11
6
3
RG
V–
Q2*
2N2222
3
7
IN
9
1.5kΩ
RCM
0.01µF
Resistance in this line causes
a small common-mode voltage
which is rejected by XTR103.
8
RLIN
Open RTD
Terminal
*Q2 optional. Provides
predictable output
current if any one
RTD connection
is broken:
IO
1
2
3
≈ 34mA
≈3.6mA
≈3.6mA
FIGURE 4. Three-Wire Connection for Remotely Located RTDs.
®
XTR103
8
There are special zener diode types specifically designed to
provide a very low impedance clamp and withstand large
energy surges. These devices normally have a diode charac-
teristic in the forward direction which also protects against
reversed loop connections. As noted earlier, reversed loop
connections would produce a large loop current, possibly
damaging RL.
If the RTD sensor is remotely located, the interference may
enter at the input terminals. For integrated transmitter as-
semblies with short connection to the sensor, the interfer-
ence more likely comes from the current loop connections.
Bypass capacitors on the input often reduce or eliminate this
interference. Connect these bypass capacitors to the IO
terminal as shown in Figure 7. Although the DC voltage at
the IO terminal is not equal to 0V (at the loop supply, VPS)
this circuit point can be considered the transmitter’s “ground.”
RADIO FREQUENCY INTERFERENCE
The long wire lengths of current loops invite radio frequency
interference. RF can be rectified by the sensitive input
circuitry of the XTR103 causing errors. This generally
appears as an unstable output current that varies with the
position of loop supply or input wiring.
1N4148
D1
Use either D1 or D2.
See “Reverse Voltage Protection.”
10
V+
0.01µF
B
D2
1N4001
XTR103
15
11
E
RL
VPS
IO
7
FIGURE 5. Reverse Voltage Protection.
NOTE: (1) Zener diode 36V: 1N4753A
or
General Semiconductor Transorb™ 1N6286A
10
Use lower voltage zener diodes with loop
power supply voltages less than 30V for
increased protection.
V+
(1)
B
XTR103
15
11
Maximum VPS must be less
E
VPS than minimum voltage rating
of zener diode.
RL
IO
7
FIGURE 6. Over-Voltage Surge Protection.
®
9
XTR103
13
IR
12
IR
4
5
V+
IN
10
V+
RZ
RG
B
E
0.01µF
RTD
RG
XTR103
15
11
0.01µF
0.01µF
6
3
RG
V–
7
IN
9
RCM
8
0.01µF
RLIN
FIGURE 7. Input Bypassing Techniques.
+12V
13
IR
12
IR
1N4148
0.01µF
4
V+
10
1µF
IN
V+
5
RG
15
11
RG
448Ω
XTR103
B
16
10
E
RG
V–
11
3
2
IO
6
12
7
VO = 0 to 5V
15
14
IN
9
3
Pt100
RCV420
RLIN
8
RZ
138Ω
100°C to
600°C
IO = 4-20mA
13
1100Ω
5
4
1.5kΩ
1µF
0.01µF
–12V
FIGURE 8. ±12V-Powered Transmitter/Receiver Loop.
13
+15V
12
1N4148
0.01µF
IR
V+
IR
1µF
1µF
4
5
10
V+
Isolated Power
from PWS740
IN
0
RG
–15V
15
XTR103
B
E
RG
16
10
RG
V–
11
3
2
IO
6
3
11
12
V+
7
1
15
14
IN
9
RTD
RCV420
RLIN
9
15
8
I
O = 4-20mA
7
8
13
RZ
ISO122
VO
5
4
1.5kΩ
0 – 5V
10
2
16
V–
0.01µF
FIGURE 9. Isolated Transmitter/Receiver Loop.
®
XTR103
10
IMPORTANT NOTICE
Texas Instruments and its subsidiaries (TI) reserve the right to make changes to their products or to discontinue
any product or service without notice, and advise customers to obtain the latest version of relevant information
to verify, before placing orders, that information being relied on is current and complete. All products are sold
subject to the terms and conditions of sale supplied at the time of order acknowledgment, including those
pertaining to warranty, patent infringement, and limitation of liability.
TI warrants performance of its semiconductor products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are utilized to the extent
TI deems necessary to support this warranty. Specific testing of all parameters of each device is not necessarily
performed, except those mandated by government requirements.
Customers are responsible for their applications using TI components.
In order to minimize risks associated with the customer’s applications, adequate design and operating
safeguards must be provided by the customer to minimize inherent or procedural hazards.
TI assumes no liability for applications assistance or customer product design. TI does not warrant or represent
that any license, either express or implied, is granted under any patent right, copyright, mask work right, or other
intellectual property right of TI covering or relating to any combination, machine, or process in which such
semiconductor products or services might be or are used. TI’s publication of information regarding any third
party’s products or services does not constitute TI’s approval, warranty or endorsement thereof.
Copyright 2000, Texas Instruments Incorporated
厂商 型号 描述 页数 下载

ETC

 		XTR100 [ ] 12 页

BB

 		XTR100AM [ Instrumentation Amplifier, 1 Func, 50uV Offset-Max, MDIP14, ] 12 页

BB

 		XTR100AP [ Instrumentation Amplifier, 1 Func, 50uV Offset-Max, PDIP14, ] 12 页

BB

 		XTR100BM [ Instrumentation Amplifier, 1 Func, 25uV Offset-Max, MDIP14, ] 12 页

BB

 		XTR100BP [ Instrumentation Amplifier, 1 Func, 25uV Offset-Max, PDIP14, ] 12 页

BB

 		XTR101 高精度，低漂移的4-20mA两线制变送器[ Precision, Low Drift 4-20mA TWO-WIRE TRANSMITTER ] 15 页

TI

 		XTR101 高精度，低漂移的4-20mA两线制变送器[ Precision, Low Drift 4-20mA TWO-WIRE TRANSMITTER ] 25 页

BB

 		XTR101AG 高精度，低漂移的4-20mA两线制变送器[ Precision, Low Drift 4-20mA TWO-WIRE TRANSMITTER ] 15 页

TI

 		XTR101AG 高精度，低漂移的4-20mA两线制变送器[ Precision, Low Drift 4-20mA TWO-WIRE TRANSMITTER ] 25 页

BB

 		XTR101AG-BI [ Instrumentation Amplifier, 1 Func, 60uV Offset-Max, CDIP14, ] 13 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.203058s
