IXFN50N120SK

型号：

IXFN50N120SK

品牌：

IXYS[ IXYS CORPORATION ]

页数：

4 页

PDF大小：

137 K

下载PDF手册
IXFN50N120SK
ID25
VDSS
RDS(on)ꢀmax
=
48 A
= 1200 V
50 mΩ
SiC Power MOSFET
=
KelvinꢀSourceꢀgateꢀconnectionꢀꢀ
KS
Part number
IXFN50N120SK
G
S
D
Dꢀ(3)
Backside:ꢀisolatedꢀ
E153432
G (2)
KSꢀ(1)
S (4)
Features / Advantages:
Applications:
Package: SOT-227Bꢀ(minibloc)
•ꢀHighꢀspeedꢀswitching
ꢀ withꢀlowꢀcapacitances
•ꢀHighꢀblockingꢀvoltage
ꢀ withꢀlowꢀRDS(on)
•ꢀEasyꢀtoꢀparallelꢀandꢀsimpleꢀtoꢀdrive
•ꢀResistantꢀtoꢀlatch-up
•ꢀSolarꢀinverters
•ꢀHighꢀvoltageꢀDC/DCꢀconverters
•ꢀMotorꢀdrives
•ꢀSwitchꢀmodeꢀpowerꢀsupplies
•ꢀUPS
•ꢀBatteryꢀchargers
•ꢀInductionꢀheating
•ꢀIsolationꢀVoltage:ꢀ3000ꢀV~
•ꢀIndustryꢀstandardꢀoutline
•ꢀRoHSꢀcompliant
•ꢀEpoxyꢀmeetsꢀULꢀ94V-0
•ꢀBaseꢀplateꢀwithꢀAluminiumꢀnitrideꢀꢀ
insolation
•ꢀRealꢀKelvinꢀsourceꢀconnection
•ꢀAdvancedꢀpowerꢀcycling
Terms & Conditions of usage
Theꢀdataꢀcontainedꢀinꢀthisꢀproductꢀdataꢀsheetꢀisꢀexclusivelyꢀintendedꢀforꢀtechnicallyꢀtrainedꢀstaff.ꢀTheꢀuserꢀwillꢀhaveꢀtoꢀevaluateꢀtheꢀsuitabilityꢀofꢀtheꢀproductꢀforꢀtheꢀintendedꢀapplicationꢀandꢀtheꢀcompletenessꢀofꢀtheꢀproductꢀ
dataꢀwithꢀrespectꢀtoꢀhisꢀapplication.Theꢀspecificationsꢀofꢀourꢀcomponentsꢀmayꢀnotꢀbeꢀconsideredꢀasꢀanꢀassuranceꢀofꢀcomponentꢀcharacteristics.Theꢀinformationꢀinꢀtheꢀvalidꢀapplication-ꢀandꢀassemblyꢀnotesꢀmustꢀbeꢀconsi-


dered.ꢀShouldꢀyouꢀrequireꢀproductꢀinformationꢀinꢀexcessꢀofꢀtheꢀdataꢀgivenꢀinꢀthisꢀproductꢀdataꢀsheetꢀorꢀwhichꢀconcernsꢀtheꢀspecificꢀapplicationꢀofꢀyourꢀproduct,ꢀpleaseꢀcontactꢀtheꢀsalesꢀoffice,ꢀwhichꢀisꢀresponsibleꢀforꢀyou.
Dueꢀtoꢀtechnicalꢀrequirementsꢀourꢀproductꢀmayꢀcontainꢀdangerousꢀsubstances.ꢀForꢀinformationꢀonꢀtheꢀtypesꢀinꢀquestionꢀpleaseꢀcontactꢀtheꢀsalesꢀoffice,ꢀwhichꢀisꢀresponsibleꢀforꢀyou.
Shouldꢀyouꢀintendꢀtoꢀuseꢀtheꢀproductꢀinꢀaviation,ꢀinꢀhealthꢀorꢀliveꢀendangeringꢀorꢀlifeꢀsupportꢀapplications,ꢀpleaseꢀnotify.ꢀForꢀanyꢀsuchꢀapplicationꢀweꢀurgentlyꢀrecommend
-ꢀtoꢀperformꢀjointꢀriskꢀandꢀqualityꢀassessments;
-ꢀtheꢀconclusionꢀofꢀqualityꢀagreements;
-ꢀtoꢀestablishꢀjointꢀmeasuresꢀofꢀanꢀongoingꢀproductꢀsurvey,ꢀandꢀthatꢀweꢀmayꢀmakeꢀdeliveryꢀdependentꢀonꢀtheꢀrealizationꢀofꢀanyꢀsuchꢀmeasures.
IXYS reserves the right to change limits, test conditions and dimensions.
20160225
© 2016 IXYS All rights reserved
1 - 4
IXFN50N120SK
MOSFET
Ratings
min. typ. max.
1200
Symbol Definitions
Conditions
max drain source voltage
VDS(max)
V
max transient gate source voltage
continous gate source voltage
VGS(max)
VGS
-10
-5
+25
+20
V
V
recommendedꢀoperationalꢀvalue
VGSꢀ=ꢀ20ꢀVꢀ
drain current
ID25
ID80
ID100
TCꢀ=ꢀꢀꢀ25°C
TCꢀ=ꢀꢀꢀ80°C
TCꢀ=ꢀ100°C
48
38
33
A
A
A
static drain source on resistance
gate threshold voltage
RDSon
IDꢀ=ꢀ40ꢀA;ꢀVGSꢀ=ꢀ20ꢀVꢀ
IDꢀ=ꢀꢀꢀ10ꢀmA;ꢀVGSꢀ=ꢀVDS
TVJꢀ=ꢀꢀꢀ25°C
TVJꢀ=ꢀ150°C
40
84
52
mΩ
mΩ
VGS(th)
TVJꢀ=ꢀꢀꢀ25°C
TVJꢀ=ꢀ150°C
2.4
2.8
2.0
tbd
V
V
drain source leakage current
gate source leakage current
internal gate resistance
IDSS
IGSS
RG
VDSꢀ=ꢀ1200ꢀV;ꢀVGSꢀ=ꢀ0ꢀVꢀ
VDSꢀ=ꢀ0ꢀV;ꢀVGSꢀ=ꢀ20ꢀVꢀ
fꢀ=ꢀ1ꢀMHz,ꢀVACꢀ=ꢀ25ꢀmV
TVJꢀ=ꢀꢀꢀ25°C
TVJꢀ=ꢀꢀꢀ25°C
1
100
µA
µA
Ω
0.25
1.8
input capacitance
output capacitance
reverse transfer (Miller) capacitance
Ciss
Coss
Crss
1895
150
10
pF
pF
pF
VDSꢀ=ꢀ1000ꢀV;ꢀVGSꢀ=ꢀ0ꢀV;ꢀfꢀ=ꢀ1ꢀMHzꢀ TVJꢀ=ꢀꢀꢀ25°C
VDSꢀ=ꢀ800ꢀV;ꢀIDꢀ=ꢀ40ꢀA;ꢀVGSꢀ=ꢀ-5/20ꢀVꢀ TVJꢀ=ꢀꢀꢀ25°C
total gate charge
gate source charge
gate drain (Miller) charge
Qg
Qgs
Qgd
115
28
37
nC
nC
nC
turn-on delay time
current rise time
turn-off delay time
current fall time
td(on)
tr
td(off)
tf
ns
ns
ns
InductiveꢀswitchingꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀTVJꢀ=ꢀꢀꢀ125°C
FreeꢀWheelingꢀDiode:ꢀBodyꢀDiodeꢀ@ꢀVGSꢀ=ꢀ-5V
VDSꢀ=ꢀ800ꢀV;ꢀID = 40A
ns
turn-on energy per pulse
turn-off energy per pulse
Eon
Eoff
VGSꢀ=ꢀ-5/20ꢀV;ꢀRG = 2.5 Ω (external)
mJ
mJ
thermal resistance junction to case
thermal resistance junction to heatsink
RthJC
RthJH
0.6
K/W
K/W
withꢀheatsinkꢀcompound;ꢀIXYSꢀtestꢀsetup
0.72
Source-Drain Diode
Symbol Definitions
IS25
Ratings
Conditions
min. typ. max.
VGSꢀ=ꢀ-5ꢀVꢀ
TCꢀ=ꢀꢀꢀꢀ25°C
TCꢀ=ꢀꢀꢀꢀ80°C
A
A
continuous source current
IS80
forward voltage drop
VSD
IFꢀ=ꢀ20ꢀA;ꢀVGSꢀ=ꢀ-5ꢀVꢀ
TVJꢀ=ꢀꢀꢀ25°C
TVJꢀ=ꢀ150°C
3.3
3.1
V
V
reverse recovery time
reverse recovery charge (intrinsic diode)
max. reverse recovery current
trr
QRM
IRM
54
285
15
ns
nC
A
VGSꢀ=ꢀ-5ꢀV;ꢀIF = 40 A
VRꢀ=ꢀ800ꢀV;ꢀ-diF /dtꢀ=ꢀ1000ꢀA/µs
TVJꢀ=ꢀꢀꢀ25°C
Note:
WhenꢀusingꢀSiCꢀBodyꢀDiodeꢀtheꢀmaximumꢀrecommendedꢀVGSꢀ=ꢀ-5V
IXYS reserves the right to change limits, test conditions and dimensions.
© 2016 IXYS All rights reserved
20160225
2 - 4
IXFN50N120SK
Package SOT-227B (minibloc)
Ratings
Symbol
IRMS
Definitions
RMS current
Conditions
min.
typ. max. Unit
perꢀterminal
A
storage temperature
operation temperature
virtual junction temperature
Tstg
Top
TVJ
-40
-40
-40
150
150
175
°C
°C
°C
Weight
MD
30
g
Nm
Nm
mounting torque
terminal torque
1.1
1.1
1.5
1.5
MT
dSpp/App
dSpb/Apb
terminal to backside
terminal to terminal
10.5 /ꢀꢀꢀ3.2
8.6 /ꢀꢀꢀ6.8
mm
mm
creepage distance on surface | striking distance through air
isolation voltage
VISOL
IISOL <ꢀ1ꢀmA;ꢀ50/60ꢀHz,ꢀ tꢀ=ꢀ1ꢀsec.
3000
2500
V
V
ꢀ
tꢀ=ꢀ1ꢀminute
Product Marking
Part No.
Logo
XXXXX
®
yywwZ
abcd
DateCode
Assembly Line Assembly Code
Ordering
Part Name
Marking on Product Delivering Mode Base Qty Ordering Code
IXFN50N120SK Tube 10 517988
Standard
IXFN50N120SK
IXYS reserves the right to change limits, test conditions and dimensions.
© 2016 IXYS All rights reserved
20160225
3ꢀ-ꢀ4
IXFN50N120SK
Outlines SOT-227B (minibloc)
Dꢀ(3)
G (2)
KSꢀ(1)
S (4)
IXYS reserves the right to change limits, test conditions and dimensions.
© 2016 IXYS All rights reserved
20160225
4 - 4
