Add on output
Without
PvR
Wire insulation material
Status LED
1 LED (green) supply
1 LED (red) instability
1 LED (yellow) output state
[Us] rated supply voltage
Supply voltage limits
Switching capacity in mA
Switching frequency
Voltage drop
12...24 V DC with reverse polarity protection
10...36 V DC
<= 100 mA (overload and short-circuit protection)
<= 250 Hz
1.5 V (closed state)
35 mA (no-load)
< 200 ms
Current consumption
Delay first up
Delay response
Delay recovery
Setting-up
< 2 ms
< 2 ms
Self-teaching
0.71 in (18 mm)
3.07 in (78 mm)
Diameter
Length
Environment
Product certifications
CE
CSA
UL
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
-13...131 °F (-25...55 °C)
-40...158 °F (-40...70 °C)
7 gn, amplitude = +/- 1.5 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
30 gn (duration = 11 ms) conforming to IEC 60068-2-27
Shock resistance
IP degree of protection
IP65 double insulation conforming to IEC 60529
IP67 double insulation conforming to IEC 60529
Ordering and shipping details
Category
22481 - SENSORS, PHOTOELECTRIC
Discount Schedule
GTIN
DS2
003389110288797
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
1
0.41999999999999998
N
Country of origin
FR
Offer Sustainability
RoHS (date code: YYWW)
Compliant - since 0821 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
Product environmental profile
Product end of life instructions
Available
Available
Contractual warranty
Warranty period
18 months
