IXFN66N85X

型号:

IXFN66N85X

品牌:

LITTELFUSE[ LITTELFUSE ]

页数:

6 页

PDF大小:

135 K

Advance Technical Information
X-Class HiPerFETTM
Power MOSFET
VDSS = 850V
ID25 = 65A
RDS(on) 65m
IXFN66N85X
D
N-Channel Enhancement Mode
Avalanche Rated
Fast Intrinsic Diode
G
S
miniBLOC, SOT-227
E153432
S
S
Symbol
Test Conditions
Maximum Ratings
G
VDSS
VDGR
TJ = 25C to 150C
TJ = 25C to 150C, RGS = 1M
850
850
V
V
VGSS
VGSM
Continuous
Transient
30
40
V
V
S
D
ID25
IDM
TC = 25C
TC = 25C, Pulse Width Limited by TJM
65
140
A
A
G = Gate
D = Drain
S = Source
IA
EAS
TC = 25C
TC = 25C
33
2.5
A
J
PD
TC = 25C
830
50
W
dv/dt
IS IDM, VDD VDSS, TJ 150°C
V/ns
Features
TJ
TJM
Tstg
-55 ... +150
150
-55 ... +150
C
C
C
International Standard Package
miniBLOC, with Aluminium Nitride
Isolation
Isolation Voltage 2500 V~
High Current Handling Capability
Fast Intrinsic Diode
VISOL
50/60 Hz, RMS
IISOL 1mA
t = 1 minute
t = 1 second
2500
3000
V~
V~
Md
Mounting Torque
Terminal Connection Torque
1.5/13
1.3/11.5
Nm/lb.in
Nm/lb.in
Avalanche Rated
Weight
30
g
Low RDS(on)
Advantages
High Power Density
Easy to Mount
Space Savings
Symbol
Test Conditions
Characteristic Values
(TJ = 25C Unless Otherwise Specified)
Min.
Typ.
Max.
BVDSS
VGS(th)
IGSS
VGS = 0V, ID = 1mA
VDS = VGS, ID = 8mA
VGS = 30V, VDS = 0V
VDS = VDSS, VGS= 0V
850
V
V
Applications
3.5
5.5
Switch-Mode and Resonant-Mode
100 nA
50 A
Power Supplies
IDSS
DC-DC Converters
PFC Circuits
AC and DC Motor Drives
Robotics and Servo Controls
TJ = 125C
3
mA
RDS(on)
VGS = 10V, ID = 33A, Note 1
65 m
© 2016 IXYS CORPORATION, All Rights Reserved
DS100715(4/16)
IXFN66N85X
Symbol
Test Conditions
Characteristic Values
SOT-227B (IXFN) Outline
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max
gfs
VDS = 10V, ID = 33A, Note 1
Gate Input Resistance
25
42
S
RGi
0.75
Ciss
Coss
Crss
8900
8900
142
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
Effective Output Capacitance
Co(er)
Co(tr)
294
pF
pF
VGS = 0V
Energy related
Time related
VDS = 0.8 • VDSS
1270
td(on)
tr
td(off)
tf
40
48
ns
ns
ns
ns
Resistive Switching Times
GS = 10V, VDS = 0.5 • VDSS, ID = 33A
(M4 screws (4x) supplied)
V
105
20
RG = 1(External)
Qg(on)
Qgs
230
53
nC
nC
nC
VGS = 10V, VDS = 0.5 VDSS, ID = 33A
Qgd
113
RthJC
RthCS
0.15C/W
0.05C/W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
66
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS , VGS = 0V, Note 1
264
1.4
trr
250
2.7
ns
μC
A
IF = 33A, -di/dt = 100A/s
QRM
IRM
VR = 100V, VGS = 0V
21.7
Note 1. Pulse test, t 300s, duty cycle, d 2%.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are
derived from a subjective evaluation of the design, based upon prior knowledge and experi-
ence, and constitute a "considered reflection" of the anticipated result. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS MOSFETs and IGBTs are covered
by one or more of the following U.S. patents: 4,860,072 5,017,508
4,881,106 5,034,796
4,835,592 4,931,844
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,534,343
6,583,505
6,727,585
6,710,405 B2 6,759,692
6,710,463
7,005,734 B2 7,157,338B2
7,063,975 B2
6,771,478 B2 7,071,537
IXFN66N85X
Fig. 2. Extended Output Characteristics @ TJ = 25ºC
Fig. 1. Output Characteristics @ TJ = 25ºC
180
160
140
120
100
80
70
60
50
40
30
20
10
0
V
= 10V
V
= 10V
GS
GS
9V
8V
9V
8V
7V
6V
60
7V
6V
40
20
0
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
0
5
10
15
20
25
30
VDS - Volts
VDS - Volts
Fig. 4. RDS(on) Normalized to ID = 33A Value vs.
Junction Temperature
Fig. 3. Output Characteristics @ TJ = 125ºC
70
60
50
40
30
20
10
0
3.4
3.0
2.6
2.2
1.8
1.4
1.0
0.6
0.2
V
= 10V
GS
V
= 10V
GS
8V
7V
I
= 66A
D
I
= 33A
D
6V
5V
-50
-25
0
25
50
75
100
125
150
0
1
2
3
4
5
6
7
8
9
10
TJ - Degrees Centigrade
VDS - Volts
Fig. 5. RDS(on) Normalized to ID = 33A Value vs.
Drain Current
Fig. 6. Normalized Breakdown & Threshold Voltages
vs. Junction Temperature
3.5
3.0
2.5
2.0
1.5
1.0
0.5
1.3
1.2
1.1
1.0
0.9
0.8
0.7
0.6
0.5
V
= 10V
GS
T = 125ºC
J
BV
DSS
T = 25ºC
J
V
GS(th)
0
20
40
60
80
100
120
140
160
180
-60
-40
-20
0
20
40
60
80
100
120
140
160
TJ - Degrees Centigrade
ID - Amperes
© 2016 IXYS CORPORATION, All Rights Reserved
IXFN66N85X
Fig. 7. Maximum Drain Current vs. Case Temperature
Fig. 8. Input Admittance
70
60
50
40
30
20
10
0
100
90
80
70
60
50
40
30
20
10
0
T
J
= 125ºC
25ºC
- 40ºC
-50
-25
0
25
50
75
100
125
150
3.5
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
8.5
TC - Degrees Centigrade
VGS - Volts
Fig. 9. Transconductance
Fig. 10. Forward Voltage Drop of Intrinsic Diode
90
80
70
60
50
40
30
20
10
0
200
180
160
140
120
100
80
T
J
= - 40ºC
25ºC
125ºC
T
J
= 125ºC
60
T
J
= 25ºC
40
20
0
0
10
20
30
40
50
60
70
80
90
100
110
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
ID - Amperes
VSD - Volts
Fig. 11. Gate Charge
Fig. 12. Capacitance
10
8
100,000
10,000
1,000
100
V
= 425V
DS
C
iss
I
I
= 33A
D
G
= 10mA
6
C
C
oss
rss
4
2
10
= 1 MHz
f
0
1
0
20
40
60
80
100 120 140 160 180 200 220 240
QG - NanoCoulombs
1
10
100
1000
VDS - Volts
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXFN66N85X
Fig. 13. Output Capacitance Stored Energy
Fig. 14. Forward-Bias Safe Operating Area
1000
100
10
120
100
80
60
40
20
0
R
Limit
)
DS(
on
25µs
100µs
1ms
1
T = 150ºC
J
T
C
= 25ºC
Single Pulse
10ms
0.1
10
100
1,000
700
0
100
200
300
400
500
600
800
900
VDS - Volts
VDS - Volts
Fig. 15. Maximum Transient Thermal Impedance
aaaaa
0.3
0.1
0.01
0.001
0.00001
0.0001
0.001
0.01
0.1
1
10
Pulse Width - Seconds
© 2016 IXYS CORPORATION, All Rights Reserved
IXYS REF: F_66N85X (U8-D901) 4-08-16
Disclaimer Notice - Information furnished is believed to be accurate and reliable. However, users should independently
evaluate the suitability of and test each product selected for their own applications. Littelfuse products are not designed for,
and may not be used in, all applications. Read complete Disclaimer Notice at www.littelfuse.com/disclaimer-electronics.
