2W10G/72-E4

型号：

2W10G/72-E4

品牌：

VISHAY[ VISHAY ]

页数：

4 页

PDF大小：

198 K

下载PDF手册

2W005G thru 2W10G

Vishay General Semiconductor

Glass Passivated Single-Phase Bridge Rectifier

Major Ratings and Characteristics

I_F(AV)

V_RRM

I_FSM

I_R

2.0 A

50 V to 1000 V

60 A

Case Style WOG

5.0 µA

V_F

1.1 V

T_jmax.

150 °C

Features

Mechanical Data

• UL Recognition, file number E54214

Case: WOG

• Ideal for printed circuit boards

Epoxy meets UL-94V-0 Flammability rating

• Typical I less than 0.5 µA

Terminals: Silver plated (E4 Suffix) leads, solderable

per J-STD-002B and JESD22-B102D

Polarity: As marked on body

• High case dielectric strength

• High surge current capability

• Solder Dip 260 °C, 40 seconds

Typical Applications

General purpose use in ac-to-dc bridge full wave rec-

tification for Power Supply, Adapter, Charger, lighting

Ballaster on Consumers and Home Appliances appli-

cations

Maximum Ratings

Ratings at 25 °C ambient temperature unless otherwise specified.

Parameter

Symbols 2W005G 2W01G 2W02G 2W04G 2W06G 2W08G 2W10G Units

Maximum repetitive peak reverse voltage

V_RRM

V_RMS

V_DC

100

200

140

200

400

280

400

2.0

600

420

600

800

560

800

1000

700

Maximum RMS voltage

Maximum DC blocking voltage

100

1000

Maximum average forward rectified current at

0.375" (9.5 mm) lead length (See Fig. 1)

I_F(AV)

Peak forward surge current single sine-wave

superimposed on rated load

I_FSM

I²t

A²sec

°C

Rating for fusing (t < 8.3 ms)

Operating junction and storage temperature

range

T_J,T_STG

- 55 to + 150

Document Number 88528

08-Jul-05

www.vishay.com

2W005G thru 2W10G

Vishay General Semiconductor

Electrical Characteristics

Ratings at 25 °C ambient temperature unless otherwise specified.

Parameter

Test condition Symbols 2W005G 2W01G 2W02G 2W04G 2W06G 2W08G 2W10G Units

Maximum instantaneous

at 2.0 A

V_F

1.1

forward voltage drop per leg

Maximum DC reverse current T_A= 25 °C

I_R

5.0

µA

at rated DC blocking voltage

per leg

500

T_A= 125 °C

Typical junction capacitance

per leg

at 4.0 V,

1 MHz

C_J

Thermal Characteristics

Ratings at 25 °C ambient temperature unless otherwise specified.

Parameter

Symbols 2W005G 2W01G 2W02G 2W04G 2W06G 2W08G 2W10G Units

Typical thermal resistance per leg ⁽¹⁾

R_θJA

R_θJL

°C/W

Notes:

(1) Thermal resistance from junction to ambient and from junction to lead at 0.375" (9.5 mm) lead length P.C.B. mounting

Ratings and Characteristics Curves

(T_A= 25 °C unless otherwise noted)

2.4

2.0

60 H_Z

Resistive or

Inductive Load

0.375"

(9.5 mm)

P.C.B.

1.6

1.2

0.8

0.4

0.1

T_J= 25°C

Pulse Width = 300 µs

1% Duty Cycle

Copper Pads

0.22 x 0.22"

(5.5 x 5.5 mm)

Capacitive Load

I_(pk)

5.0

I_(AV)

(Per Leg)

0.01

0.4

1.0

Instantaneous Forward Voltage (V)

100

125

150

0.6

0.8

1.2

1.4

1.6

Ambient Temperature (°C)

Figure 1. Derating Curve Output Rectified Current

Figure 3. Typical Forward Characteristics Per Leg

100

T_A= 25°C

T_J= 125°C

Single Sine-Wave

T_J= 100°C

0.1

T_J= 25°C

1.0 Cycle

0.01

100

Number of Cycles at 60 H_Z

100

Percent of Rated Peak Reverse Voltage (%)

Figure 2. Maximum Non-Repetitive Peak Forward Surge Current

Per Leg

Figure 4. Typical Reverse Leakage Characteristics Per Leg

www.vishay.com

Document Number 88528

08-Jul-05

2W005G thru 2W10G

Vishay General Semiconductor

100

= 25 °C

f = 1.0 MH_Z

Vsig = 50mVp-p

0.1

0.01

0.1

100

0.1

100

Reverse Voltage (V)

t, Heating Time (sec.)

Figure 6. Typical Transient Thermal Impedance

Figure 5. Typical Junction Capacitance Per Leg

Package outline dimensions in inches (millimeters)

Case Style WOG

0.388 (9.86)

0.348 (8.84)

0.220 (5.6)

0.160 (4.1)

1.0

(25.4)

MIN.

0.032 (0.81)

0.028 (0.71)

0.060 (1.52)

0.020 (0.51)

0.220 (5.6)

0.180 (4.6)

0.348 (8.84)

0.308 (7.82)

0.220 (5.6)

0.180 (4.6)

Document Number 88528

08-Jul-05

www.vishay.com

Legal Disclaimer Notice

Vishay

Notice

Specifications of the products displayed herein are subject to change without notice. Vishay Intertechnology, Inc.,

or anyone on its behalf, assumes no responsibility or liability for any errors or inaccuracies.

Information contained herein is intended to provide a product description only. No license, express or implied, by

estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Vishay's

terms and conditions of sale for such products, Vishay assumes no liability whatsoever, and disclaims any express

or implied warranty, relating to sale and/or use of Vishay products including liability or warranties relating to fitness

for a particular purpose, merchantability, or infringement of any patent, copyright, or other intellectual property right.

The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.

Customers using or selling these products for use in such applications do so at their own risk and agree to fully

indemnify Vishay for any damages resulting from such improper use or sale.

Document Number: 91000

Revision: 08-Apr-05

www.vishay.com
