Part Number:
Status:
1200800003
Active
Brad Ultra-Lock Connection System
Overview:
Description:
Ultra-Lock (M12) In-Line Splitter, 4 Poles, 3-Female (Straight) to 4-Male (90°), 22 AWG
PVC Cable, 0.30m Length
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
Series image - Reference only
LR6837
General
Product Family
Series
EU ELV
Not Reviewed
Industrial Tees and Splitters
120080
IP Rating
Overview
Product Name
Type
IP69K
EU RoHS
China RoHS
Brad Ultra-Lock Connection System
Ultra-Lock (M12)
Splitter - In-line
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
For more information, please visit Contact US
UPC
78678887282
Physical
Color - Cable Jacket
Drop Connector
Drop Gender
Keyway
Yellow
Ultra-Lock (M12)
Male
Single
No
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Reviewed
Not Reviewed
LED Indicator
Left Trunk Connector
Left Trunk Gender
Leg 1 Length
Ultra-Lock (M12)
Female
1.0m
1.0m
PVC
Search Parts in this Series
120080 Series
Leg 2 Length
Material - Cable Jacket
Material - Connector Body
Material - Coupling Nut
Poles
Right Trunk Connector
Right Trunk Gender
Temperature Range - Operating
PVC
Nickel-plated Brass
3 Female/4 Male
Ultra-Lock (M12)
Female
-30°C to +90°C
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
250V AC/DC
Material Info
Engineering Number
WW4A30A09M010
SD-120080-019
Reference - Drawing Numbers
Sales Drawing
