Conductive Polymer Tantalum Solid Capacitors
Surface Mount Type
Series : TPG
Features
●
Small size, Low profile (L3.5 × W 2.8 × H 1.1 mm)
Large capacitance (220 μF max.)
RoHS compliance, Halogen free
●
●
Specifications
Size code
B1G
B15G
Category temperature range
Rated voltage range
Category voltage range
Rated capacitance range
Capacitance tolerance
Leakage current
–55 °C to +105 °C
2.5 V.DC to 12.5 V.DC
2.0 V.DC to 10.0 V.DC
33 ꢀF to 220 ꢀF
2.5 V.DC to 6.3 V.DC
2.0 V.DC to 5.0 V.DC
150 ꢀF to 220 ꢀF
20 ꢁ (120 Hz / + 20 °C)
Please see the attached characteristics list
Please see the attached characteristics list
Rated voltage × 1.15
Dissipation factor (tan d)
Surge voltage (V.DC)
+85 °C, 1000 h rated voltage applied
Capacitance change Within 20 ꢁ of the initial value
tan d
Endurance
< 1.5 times of the initial limit
DC leakage current Within the initial limit
+60 °C, 90 ꢁ to 95 ꢁ, 500 h, No-applied voltage
Capacitance change Within +40 ꢁ, −20 ꢁ of the initial value
Damp heat
(Steady State)
tan d
< 1.5 times of the initial limit
< 3 times of the initial limit
DC leakage current
Marking
Dimensions (not to scale)
L
R.Cap. code
Polarity marking(+)
R. Voltage code
Lot. No.
S
S
W1
Unit : mm
R. Voltage (V.DC)
2.5
e
4.0
g
6.3
j
8.0
k
10.0 12.5
+0.3
−0.1
+0.3
Size code
B1G
L
W
H 0.1
1.1
1.4
S 0.2 W1 0.1
−0.1
Code
A
B
3.5
3.5
2.8
2.8
0.8
0.8
2.2
2.2
R. Cap. (μF) 33
Code N7
47
S7
100
A8
150
E8
220
J8
B15G
Externals of figure are the reference.
✽
Characteristics list
Case size (mm)
Specifications
Standard
Floor life
Reflow Reflow
Rated Rated Category
Category
temp.
Rated
✽1
Size
code
Ripple
Min.
✽2
✽4
Series voltage temp. voltage
capacitance
ESR
LC
✽3
L
W
H
current
(mAr.m.s.)
tan d
Part number
Packaging Q'ty
Temp
Temp
(V.DC) (°C) (V.DC) (°C) (ꢀF)
(mΩ max.)
(ꢀA)
(pcs) 260°C 250°C
< <
85
85
85
85
85
2.0 105
2.0 105
3.2 105 220 3.5 2.8 1.4
5.0 105 3.5 2.8 1.1
3.5 2.8 1.1 B1G 1000 70
0.10 55.0 2R5TPG220M
2500
2.5
4
220
3.5 2.8 1.4
1400 30/300 kHz 0.10 110.0 2R5TPG220MUG 2500
B15G
1000 70
1000 70
0.10 88.0 4TPG220M
0.10 63.0 6TPG100M
0.10 63.0 6TPG100MG
2500
2500
2500
5.0 105 100 3.5 2.8 1.1 B1G 1100 55
TPG 6.3 85
5.0 105
5.0 105
5.0 105
6.3 105
8.0 105
3.5 2.8 1.1
3.5 2.8 1.4
3.5 2.8 1.4
1200 35/300 kHz 0.10 126.0 6TPG100MZGD 2500
3
3
85
85
1000 70
0.10 94.5 6TPG150M
2500
2500
2500
2500
2500
150
B15G
1200 35/300 kHz 0.10 189.0 6TPG150MZG
8
85
47 3.5 2.8 1.1
47 3.5 2.8 1.1 B1G 1000 70
33 3.5 2.8 1.1 1000 70
1000 70
0.10 37.6 8TPG47M
0.10 47.0 10TPG47M
0.10 41.3 12TPG33M
10 85
12.5 85 10.0 105
1 Ripple current (100 kHz/ +45 °C ), 2 ESR (100 kHz/+20 °C) 3 tan d (120 Hz/+20 °C) 4 After 5 minutes
✽
✽
✽
✽
Please refer to each page in this catarog for “Reflow conditions” and “Taping specifications”.
◆
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Jun. 2018
