PLASTIC FILM CAPACITORS
Metallized Polypropylene Film AC Power Capacitor
EXH
Self-healing and non-inductive wound by metallized film, with flame-retardant expoxy
resin coating for humidity resistance.
Compliant to the RoHS directive (2011/65/EU).
Application
Motor running
Specifications
Type numbering system (Example : 250VAC 6 F)
µ
Item
Performance Characteristics
1
2
3
4
5
6
7
8
9 10 11 12
Maximum permissible temperature
Minimum amibient temperature
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Loss factor
+85˚C ( Z )
– 25˚C ( B )
250VAC
E X H 2 E 6 0 5 H R P T
AC usage applicable ( T )
Tinned CP wire( P )
6 to 12µF
Polypropylene film( R )
+10 to –5%
Capacitance tolerance (+10% to -5% : H)
0.12% or less (at 20˚C 50/60Hz 200VAC)
Between Terminals : Rated Voltage × 175% 10 secs.
Rated capacitance (6µF)
Rated voltage (250V)
Withstand Voltage
Between Terminals conected together and case : 2000VAC 60 secs.
Between Terminals connected together and case
Series name
Type
Insulation Resistance
: 1000MΩ or more (at 500VDC
)
Flame retardant epoxy resin
40D (40,000h)
Encapsulation
Current duration class
Safety Mechanism
Non-included
Drawing
W MAX
T MAX
H MAX
1.5MAX
25MIN
φ0.8 0.05
+1.0
P
–2.0
Straight lead type
Dimensions
Unit : mm
250VAC (2E)
Cap. (µF)
T
W
H
P
6.0
7.0
8.0
9.0
10.0
12.0
605
705
805
905
106
126
14.0
14.5
15.5
16.5
17.5
18.5
36.0
36.0
36.0
36.0
36.0
36.0
25.5
27.5
28.5
29.5
30.5
31.5
32.5
32.5
32.5
32.5
32.5
32.5
Since rating other than the above can be manufactured a please ask for detail.
