Wire insulation material
Status LED
PvR
1 LED (green) supply
1 LED (red) instability
1 LED (yellow) output state
[Us] rated supply voltage
Supply voltage limits
24...240 V AC
24...240 V DC
20...264 V AC
20...264 V DC
Switching capacity in mA
Switching frequency
Voltage drop
3 A (cos φ = 1 for 0.5 million cycles at 1 operating cycle per second at 250 V)
<= 20 Hz
<= 1.5 V (closed state)
Power consumption in W
Time delay range
Delay first up
3 W AC/DC
0...10 s monostable, on-delay or off-delay (programmable) delay
< 300 ms
Delay response
Delay recovery
Setting-up
< 25 ms
< 25 ms
Self-teaching
Electrical durability
Depth
500000 cycles, cos φ = 1, 60 cyc/mn at 250 V
1.97 in (50 mm)
1.97 in (50 mm)
0.71 in (18 mm)
0.39 lb(US) (0.175 kg)
Height
Width
Product weight
Environment
Product certifications
CE
CSA
UL
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
-13...131 °F (-25...55 °C)
-40...158 °F (-40...70 °C)
7 gn, amplitude = +/- 1.5 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
30 gn (duration = 11 ms) conforming to IEC 60068-2-27
IP65 double insulation conforming to IEC 60529
Shock resistance
IP degree of protection
Ordering and shipping details
Category
22481 - SENSORS, PHOTOELECTRIC
Discount Schedule
GTIN
DS2
003389110703184
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
1
0.82000000000000006
N
Country of origin
ID
Offer Sustainability
RoHS (date code: YYWW)
Compliant - since 0903 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
Product environmental profile
Product end of life instructions
California proposition 65
- - - - - - - Substance 1
Available
Available
WARNING: This product can expose you to chemicals including:
Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and
- - - - - - - Substance 2
Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other
reproductive harm.
- - - - - - - More information
For more information go to www.p65warnings.ca.gov
