IXFA16N60P3 IXFP16N60P3
IXFH16N60P3
Symbol
Test Conditions
Characteristic Values
TO-220 Outline
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max
gfs
VDS = 20V, ID = 0.5 • ID25, Note 1
Gate Input Resistance
10
17
S
RGi
2.3
Ciss
Coss
Crss
1830
217
8.6
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
20
13
42
8
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
ns
RG = 5 (External)
Pins: 1 - Gate
ns
2 - Drain
3 - Source
Qg(on)
Qgs
36
9
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
13
RthJC
RthCS
0.36 C/W
TO-220
TO-247
0.50
0.21
C/W
C/W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min.
Typ.
Max
IS
VGS = 0V, Note1
16
A
A
TO-247 Outline
ISM
VSD
Repetitive, pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
48
1.4
V
trr
QRM
IRM
250
C
ns
IF = 8A, -di/dt = 100A/μs
0.7
7.6
VR = 100V
A
Note 1. Pulse test, t 300s, duty cycle, d 2%.
1 - Gate
2,4 - Drain
3 - Source
TO-263 Outline
1 = Gate
2 = Drain
3 = Source
4 = Drain
Bottom Side
