IXFA20N50P3 IXFA20N50P3
IXFQ20N50P3 IXFH20N50P3
Symbol
Test Conditions
Characteristic Values
(TJ = 25C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 20V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
Gate Input Resistance
11
18
S
Ciss
Coss
Crss
1800
230
8.3
pF
pF
pF
RGi
2.3
td(on)
tr
td(off)
tf
10
5
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 5 (External)
43
9
Qg(on)
Qgs
36
7
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
13
RthJC
RthCS
0.36 C/W
C/W
TO-220
TO-247 & TO-3P
0.50
0.25 C/W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
20
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
80
1.4
250
trr
ns
A
IF = 10A, -di/dt = 100A/s
IRM
QRM
8.0
0.6
VR = 100V, VGS = 0V
μC
Note
1. Pulse test, t 300s, duty cycle, d 2%.
PRELIMANARY TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are
derived from a subjective evaluation of the design, based upon prior knowledge and experi-
ence, and constitute a "considered reflection" of the anticipated result. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
