Part Number:
Status:
1200800378
Active
Brad Ultra-Lock Connection System
Overview:
Description:
Ultra-Lock (M12) Double-Ended Cordset, 5 Poles, Female (Straight) to Male (90°), 22
AWG, PVC Cable, 1.0m (3.28') Length
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
Series image - Reference only
LR6837
General
Product Family
Series
EU ELV
Not Reviewed
Industrial Cordsets
120080
EU RoHS
China RoHS
Connector End A
Connector End B
IP Rating
Material - Contact
Overview
Ultra-Lock (M12)
Ultra-Lock (M12)
IP68
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Copper Alloy
Brad Ultra-Lock Connection System
Ultra-Lock (M12)
EtherNet
Product Name
Protocol
Not Reviewed
Region
America
For more information, please visit Contact US
Type
UPC
Double Ended
78678884939
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Reviewed
Not Reviewed
Physical
Cable Diameter
Cable Length
Color - Cable Jacket
Coupling Style
Gender
Keyway
5.72mm (.225")
1.0m (3.28')
Yellow
Push to Lock
Female-Male
Single
Search Parts in this Series
120080 Series
LED Indicator
No
Material - Cable Jacket
Material - Connector Body
Material - Coupling Nut
Material - O-Ring
Material - Plating Mating
Orientation
PVC
PVC
Nickel-plated Brass
Fluoro-elastomer
Gold over Nickel
90° to Straight
5
Poles
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
-30°C TO +80°C
22
UL 2661
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
300V AC/DC
Material Info
Engineering Number
WW5032A09M010
SD-120080-017
Reference - Drawing Numbers
Sales Drawing
