Inductive sensors
Inductive sensors special versions
IZRM 18N1501
dimension drawing
M18 x 1
40 x 40 20
general data
mounting type
special type
shielded
2 adjust. switching points
2 ... 5 mm
operating range
hysteresis
1 ... 15 % of Sr
LED red
output indicator
electrical data
switching frequency
voltage supply range +Vs
current consumption max.
output circuit
< 1 kHz
14 ... 30 VDC
20 mA
NPN make function (NO)
voltage drop Vd
< 2 VDC
< 200 mA
yes
output current
connection diagram
short circuit protection
reverse polarity protection
yes
(1)
+VS
IZRM
mechanical data
type
Z
Z
(4)
output 1
output 2
cylindrical threaded
PBT
~
(2)
~
~
material (sensing face)
housing material
dimension
(3)
0 V
brass nickel plated / PBT / PC
18 mm
housing length
connection types
111 mm
screw connections
• two adjustable switching points
ambient conditions
operating temperature
protection class
0 ... +60 °C
IP 65
www.baumer.com
15/10/2011
