PRELIMINARY
High Luminous Efficacy Warm White LED Emitter
LZ1-00WW02
Photo TBD
Key Features
.
.
.
.
.
.
.
.
.
.
High Luminous Efficacy Warm White LED
Ultra-small foot print – 4.4mm x 4.4mm
Surface mount ceramic package with integrated glass lens
Low Thermal Resistance (6.0°C/W)
High Luminous Flux density
Color Rendering Index CRI 85
JEDEC Level 1 for Moisture Sensitivity Level
Lead (Pb) free and RoHS compliant
Reflow solderable
Emitter available on Standard or Miniature MCPCB (optional)
Typical Applications
.
.
.
.
.
.
General lighting
Museum lighting
Retail & high-end interior lighting
Hospitality lighting
Accent & Task lighting
Architectural Detail lighting
Description
The LZ1-00WW02 Warm White LED emitter provides power in an extremely small package. With a 4.4mm x
4.4mm ultra-small footprint, this package provides exceptional luminous flux density. LED Engin’s patent-pending
thermally insulated phosphor layers provide a spatially uniform color across the radiation pattern and a consistent
CCT, CRI 85 and R9 30 over time and temperature. The high quality materials used in the package are chosen to
optimize light output and minimize stresses which results in monumental reliability and lumen maintenance. The
robust product design thrives in outdoor applications with high ambient temperatures and high humidity.
COPYRIGHT © 2014 LED ENGIN. ALL RIGHTS RESERVED.
LZ1-00WW02 (PRELIMINARY - 10/31/2014)
LED Engin | 651 River Oaks Parkway | San Jose, CA 95134 USA | ph +1 408 922 7200 | fax +1 408 922 0158 | em sales@ledengin.com | www.ledengin.com
Part number options
Base part number
Part number
Description
LZ1-00WW02-xxxx
LZ1-10WW02-xxxx
LZ1 emitter
LZ1 emitter on Standard Star MCPCB
Bin kit option codes
WW, Warm White (2700K – 3500K)
Min
flux
Bin
Kit number
suffix
Chromaticity bins
Description
6A1, 6A2, 6B1, 6B2, 6A4, 6A3, 6B4, 6B3, 6D1, 6D2,
6C1, 6C2, 6D4, 6D3, 6C4, 6C3, 7A1, 7A2, 7B1, 7B2,
7A4, 7A3, 7B4, 7B3, 7D1, 7D2, 7C1, 7C2, 7D4, 7D3,
7C4, 7C3, 8A1, 8A2, 8B1, 8B2, 8A4, 8A3, 8B4, 8B3,
8D1, 8D2, 8C1, 8C2, 8D4, 8D3, 8C4, 8C3
8A1, 8A2, 8B1, 8B2, 8A4, 8A3, 8B4, 8B3, 8D1, 8D2,
8C1, 8C2, 8D4, 8D3, 8C4, 8C3
7A1, 7A2, 7B1, 7B2, 7A4, 7A3, 7B4, 7B3, 7D1, 7D2,
7C1, 7C2, 7D4, 7D3, 7C4, 7C3
6A1, 6A2, 6B1, 6B2, 6A4, 6A3, 6B4, 6B3, 6D1, 6D2,
6C1, 6C2, 6D4, 6D3, 6C4, 6C3
0000
N
full distribution flux; full distribution CCT
0027
0030
0035
N
N
N
full distribution flux; 2700K ANSI bin
full distribution flux; 3000K ANSI bin
full distribution flux; 3500K ANSI bin
Notes:
1. Default bin kit option is -0000
COPYRIGHT © 2014 LED ENGIN. ALL RIGHTS RESERVED.
LZ1-00WW02 (PRELIMINARY - 10/10/2014)
2
LED Engin | 651 River Oaks Parkway | San Jose, CA 95134 USA | ph +1 408 922 7200 | fax +1 408 922 0158 | em sales@ledengin.com | www.ledengin.com
Warm White Chromaticity Groups
Standard Chromaticity Groups plotted on excerpt from the CIE 1931 (2°) x-y Chromaticity Diagram.
Coordinates are listed below in the table.
COPYRIGHT © 2014 LED ENGIN. ALL RIGHTS RESERVED.
LZ1-00WW02 (PRELIMINARY - 10/10/2014)
3
LED Engin | 651 River Oaks Parkway | San Jose, CA 95134 USA | ph +1 408 922 7200 | fax +1 408 922 0158 | em sales@ledengin.com | www.ledengin.com
Warm White bin coordinates
Bin code CIEx
0.3889
CIEy
0.369
0.3768
0.38
0.372
