Part Number: XZCB25X92S-4
3.5x3.5 mm SMD CHIP LED LAMP
Luminous Intensity
CIE127-2007*
(IF=150mA)
cd
Luminous Flux
CIE127-2007*
(IF=150mA)*
lm
Viewing
Angle
2 θ 1/2 [1]
Part
Number
Emitting
Color
Emitting
Material
Lens-color
min.
0.7*
typ.
min.
2.4*
typ.
3.3*
XZCB25X92S-4
Blue
InGaN
Water Clear
1.295*
120°
Notes:
1. θ 1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value.
2. Luminous intensity / luminous flux: +/-15%.
3. LEDs are binned according to their luminous flux.
* Luminous intensity / luminous flux value is in accordance with CIE127-2007 standards.
Absolute Maximum Ratings at TA=25°C
Parameter
Symbol
PD
Value
Unit
mW
°C
Power Dissipation
600
110
Junction Temperature [1]
Operating Temperature
Storage Temperature
DC Forward Current[1]
Peak Forward Current [2]
Reverse Voltage
TJ
Top
Tstg
IF
-40 To +85
-40 To +85
150
°C
°C
mA
mA
V
IFM
VR
300
5
Thermal Resistance [1]
(Junction/ambient)
Rth j-a
Rth j-S
180
°C/W
Thermal Resistance [1]
(Junction/solder point)
85
°C/W
V
Electrostatic Discharge Threshold (HBM)
Notes:
1.Results from mounting on PC board FR4(pad size≥70mm2), mounted on pc board-metal core PCB is recommend
for lowest thermal Resistance.
8000
2.1/10 Duty Cycle, 0.1ms Pulse Width.
Electrical / Optical Characteristics at TA=25°C
Parameter
Symbol
Value
Unit
Forward Voltage IF = 150mA [Min.]
Forward Voltage IF = 150mA [Typ.]
Forward Voltage IF = 150mA [Max.]
Allowable Reverse Current [Max.]
2.7
3.5
4.0
85
VF [2]
V
IR
mA
nm
nm
Wavelength at peak emission IF=150mA CIE127-2007* [Typ.]
Dominant Wavelength IF=150mA CIE127-2007* [Typ.]
λ peak
λ dom [1]
445*
450*
Δλ
20
nm
Spectral bandwidth at 50% Φ REL MAX IF = 150mA [Typ.]
Temperature coefficient of λ peak
IF = 150mA, - 10°C ≤ T ≤ 100°C [Typ.]
TC λ peak
0.12
nm/°C
Temperature coefficient of λ dom
IF = 150mA, - 10°C ≤ T ≤ 100°C [Typ.]
TC λ dom
0.10
-2.3
nm/°C
mV/°C
Temperature coefficient of VF
TCV
IF = 150mA, - 10°C ≤ T≤ 100°C [Typ.]
Notes:
1.The dominant Wavelength (λd) above is the setup value of the sorting machine. (Tolerance λd : ±1nm. )
2. Forward Voltage: +/-0.1V.
*Wavelength value is in accordance with CIE127-2007 standards.
Dec 16, 2013
XDSB4088 V3-Z Layout: Maggie L.
P. 3/6
