Ordering Information
VX-706 0 - E A E - 305 0 - 100M000000
Frequency
Model Code
Enable
0: No Enable (only available @ HCMOS)
1: Enable
Height
0: 1.6mm (G322)
Stability Code
305: 30ppm
Supply Voltage
D: 5V
E: 3.3V
Temperature Range
E: -40°C to +85°C
RF Output Code
A: HCMOS
C: PECL
Notes:
1. Contact factory for improved stabilities or additional product options. Not all options and codes are available at all
frequencies.
2. Unless other stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency
control voltage, load, temperature (25°C).
3. Phase noise degrades with increasing output frequency.
4. Subject to technical modification.
5. Contact factory for availability.
