COM Express® Compact Size Type 2 Module with
Dual Core Intel® Atom™ Processor
Express-LPC
Features
Single/Dual-core Intel® Atom™ Processor
with Mobile Intel® ICH8-M Chipset
Up to 4 GB DDR3 SDRAM at 800 MHz
Five free PCIe x1 lanes (optional PCIe x4)
VGA and LVDS support
SATA 3 Gb/s, Gigabit Ethernet, USB 2.0
Specifications
I/O Interfaces
Chipset
Core System
CPU
Intel® I/O Controller Hub 8 Mobile (ICH8M)
Supports up to eight ports USB 2.0
Three ports SATA 3 Gb/s
N455: Single-core Intel® Atom™ processor 1.66 GHz at 6.5 W
D425: Single-core Intel® Atom™ processor 1.80 GHz at 10 W
D525: Dual-core Intel® Atom™ processor 1.80 GHz at 13 W
USB
SATA
Memory
Dual SODIMM sockets support up to 4 GB of non-ECC
667/800 MHz DDR3 memory (N455 supports max. 2 GB)
Intel® I/O Controller Hub 8 Mobile (ICH8-M)
Super I/O
Chipset
L2 Cache
BIOS
BIOS support for legacy free or legacy with two types of
Super I/O (Winbond W83627HG and W83627DHG)
1 MB for D525, 512KB for N455 & D425
AMIBIOS® 8 with CMOS backup in 16 Mbit SPI flash
supports SPI BIOS on carrier (COM.0 R2.0)
TPM (optional)
Chipset
Hardware Monitor
Debug Interface
Supply voltages and CPU temperature
XDP SFF-26 extension for ICE debug
Infineon SLB9635TT1.2
TPM 1.2
Type
Embedded Features
Instant on with Intel Bootloader support, OEM BIOS settings,
Board Info & Statistics, ACPI 3.0, Smart Battery Management
support, Watchdog with programmable timer ranges
Power
Input Power
Expansion Busses
6 PCI Express x1: 0/1/2/3/4 are free, 5 is occupied by GbE;
0/1/2/3 x1 can be optionally configured as 1 PCIe x4
AT mode (12 V +/- 5%) and ATX mode (12 V and 5 Vsb +/- 5%)
Supports S0, S1, S3, S4, S5
Power States
32-bit PCI: PCI rev. 2.3 at 33MHz, supporting 4 bus masters
LPC bus, SMBus (system), I2C (user)
Power Consumption
10 W (with N455 CPU and 2 GB memory typical)
Smart Battery Support Yes
Video
GPU Core
Mechanical and Environmental
Integrated in CPU with Gen3.5+ GFX Core and render core
frequency at 200 MHz (N455) and 400 MHz (D425/D525)
Form Factor
Compact size: 95 mm x 95 mm
Intel® Dynamic Video Memory Technology 4.0 support
Operating Temperature Standard: 0°C to +60°C
Integrated Video
Feature Support
Storage Temperature
Humidity
-20°C to +80°C
DirectX 9 compliant Pixel Shader v2.0
90% at +60°C
400 MHz render clock frequency
Shock
15G peak-to-peak, 11ms duration, non-operating
Non-operating: 1.88 Grms, 5-500 Hz, each axis
Operating: 0.5 Grms, 5-500 Hz, each axis
COM Express® Type 2, COM.0 R2.0
Compact form factor 95 mm x 95 mm
CE, FCC
2 display ports: LVDS and RGB
Intel® Clear Video Technology
Vibration
MPEG2 Hardware Acceleration, ProcAmp
Analog RGB graphics, resolution up to 2048x1536@ 60 Hz
Single 18-bit channel, resolution up to 1366x768, 18bpp
Compatibility
Certification
VGA Interface
LVDS Interface
Audio
Chipset
Operating Systems
Integrated in Intel® I/O Controller Hub 8 Mobile (ICH8M)
On carrier (ALC886)
Standard Support
Windows XPe/ Vista, Windows 7, Linux
Audio Codec
Extended Support (BSP) Embedded XP / 2009 support package, Linux 2.6.x BSP,
VxWorks 6.x BSP, AIDI Library for Windows and Linux
Ethernet
Chipset
Intel® 82583V Gigabit Ethernet Controller
10/100/1000 Mbps Ethernet
Interface
