Part Number:
Status:
0988533062
Active
Squib Right-Angle AK-2 Cable Assemblies
SQUIB Right-Angle AK-2 Cable Assembly, Code 2, 1.0m Length
Overview:
Description:
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
Cable Assemblies
98853
Series image - Reference only
Assembly Configuration
Comments
Connector to Connector
Overview
Product Name
UPC
Single Ended Connector
Cover (Yellow), CPA (Orange)
Squib Connector-to-Pigtail
Squib Right-Angle AK-2 Cable Assemblies
Squib
EU ELV
Compliant
EU RoHS
Compliant
China RoHS
889056024013
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Physical
Cable Length
Circuits (Loaded)
Color - Resin
Gender
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
1.0m
2
Light Green
Female
Yes
Copper Alloy
Gold
Gold
PBT
15.975/g
Bag
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
Net Weight
Packaging Type
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Single Ended
3.10mm
0.508µm
0.508µm
Yes
China ROHS
ELV
RoHS Phthalates
Green Image
Compliant
Not Reviewed
Termination Interface: Style
Waterproof / Dustproof
Wire Insulation Diameter
Wire Size AWG
AK2 Standard
No
1.6 mm MAX
20
Search Parts in this Series
98853 Series
Wire/Cable Type
FLRY-A
Mates With
Electrical
USCAR Drawing 999-U-002-1-Z03,
Rev. A00, Date: 2007-Aug-24. ISO/TS
19072-4:2009(E), Dated: 2009-Jul-21.
Current - Maximum per Contact
Shielded
6.7A
No
