Product data sheet
EZM11200JCBUMS
Characteristics
EZ Meter Main Energy Reducing Maint Switch,
1200A main, 100 kAIC Breaker, UG, 1P
Price** : 38,025.00 USD
Main
Range of product
Product or component type
Main type
EZ meter-pak
Meter center main unit
Main Circuit Breaker
Included Items
Circuit breaker 1) 2P 1200 A 100 kA main supply, ready assembled
Closing plate
Complementary
Main rated current
Bus rated current
Material
1200 A
1200 A
Aluminium busbar
Steel
Enclosure material
[Ue] rated operational voltage
Device mounting
Number of Phases
120/240 V AC
Wall mounted
1 phase in
1 phase out
Service feed location
Electrical connection
UG
Lugs 1 AWG 6...300 kcmil aluminium/copper) ground
Lugs 4 AWG 3/0...500 kcmil aluminium/copper) phase and neutral
Wiring configuration
Height
3-wire
65.31 in (1658.87 mm)
23.70 in (601.98 mm)
13.62 in (345.95 mm)
Width
Depth
Environment
Product certifications
UL listed
Enclosure Rating
NEMA 3R
Mar 23, 2020
1
