Part No.
QTHA-FRS0
5/16"-24 UNF x male Quick-test, no check-valve, S.S.
Connect a Quick-test hose directly to a DP
transmitter or gauge valve using the bleeder
port when the transmitter is not mounted on a
3 valve manifold or gauge valve or when the
manifold is not easily accessible.
QTHA-FRS0
Specs/Attributes
Compatible with
Rosemount 2051 Series DP Pressure Transmitters, Rosemount 3051 Series DP Pressure Transmitters,
Yokogawa EJ series DP Pressure Transmitters, Anderson Greenwood M25 Block and Bleed Valves, Anderson
Greenwood M251 Block and Bleed Valves
Country of origin
Materials
USA
Stainless Steel
Max Pressure
5000 PSI / 345 bar / 35 MPa
Max Temperature
Max Vacuum
140 °F / 60 °C
0.00 InHg / 0.0 kPa
Media Compatibility
Min Temperature
Seal Materials
Wrench Size
Air, Inert Gas, Natural Gas, Petroleum Based Oil, Water
0 °F / -18 °C
Buna-N
9/16 In
15 mm
Dimensions
H: 2.16 in (5.49 cm) x W: 0.56 in (1.42 cm)
