Conductive Polymer Tantalum Solid Capacitors
Surface Mount Type
Series : TPC
Features
●
Low profile (Height 1.1 mm)
RoHS compliance, Halogen free
●
Specifications
Size code
B1
D2
Category temperature range
Rated voltage range
Category voltage range
Rated capacitance range
Capacitance tolerance
Leakage current
–55 °C to +105 °C
6.3 V.DC to 12.5 V.DC
5.0 V.DC to 10.0 V.DC
10 μF to 47 μF
6.3 V.DC to 10 V.DC
6.3 V.DC to 10 V.DC
68 μF to 330 μF
20 ꢀ (120 Hz / + 20 °C)
Please see the attached characteristics list
Please see the attached characteristics list
Rated voltage × 1.15
Dissipation factor (tan d)
Surge voltage (V.DC)
+105 °C 2000h, (B1 size : 1000h) rated voltage appled
✽ Rated temp. +85 °C 1000h rated voltage applied
Capacitance change Within 20 ꢀ of the initial value
Endurance
tan d
< 1.5 times of the initial limit
DC leakage current Within the initial limit
+60 °C, 90 ꢀ to 95 ꢀ, 500 h, No-applied voltage
Capacitance change Within +40 ꢀ, −20 ꢀ of the initial value
Damp heat
(Steady State)
tan d
< 1.5 times of the initial limit
< 3 times of the initial limit
DC leakage current
Marking
Dimensions (not to scale)
B1 Size
D2 Size
L
Polarity marking(+)
Polarity marking(+)
R.Cap. code
Lot. No.
R.Cap. code
Lot. No.
R. Voltage code
R. Voltage code
S
S
W1
R. Voltage (V.DC)
6.3
j
8.0
k
10.0 12.5
Unit : mm
Code
A
B
Size code
B1
L 0.2 W 0.2 H 0.1
S 0.2 W1 0.1
B1 Size
3.5
2.8
1.1
0.8
2.2
R. Cap. (ꢁF) 10
Code A7
15
E7
22
J7
33
N7
47
S7
D2
7.3
4.3
1.9
1.3
2.4
Externals of figure are the reference.
✽
Characteristics list
Case size (mm)
Specifications
Standard
Rated Rated Category Category
Rated
✽1
Size
Ripple
Min.
✽2
✽4
Series voltage temp. voltage
temp.
capacitance
ESR
LC
✽3
code
L
W
H
current
(mAr.m.s.)
1100
1000
1700
1900
1900
1000
1900
1700
1700
800
tan d
Part number
Packaging Q'ty
(pcs)
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
(V.DC) (°C) (V.DC) (°C) (μF)
(mΩ max.)
(μA)
85
85
5.0 105
5.0 105
3.5 2.8 1.1
3.5 2.8 1.1
6.3 105 100 7.3 4.3 1.9 D2
6.3 105 150 7.3 4.3 1.9 D2
5.0 105 330 7.3 4.3 1.9 D2
55
70
45
40
40
70
40
45
45
80
80
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
29.6
29.6
63.0
94.5
207.9
17.6
120.0
68.0
100.0
12.5
6TPC47M
47
B1
6TPC47MB
6TPC100M
6TPC150M
6TPC330MA
8TPC22M
8TPC150M
10TPC68M
10TPC100M
12TPC10M
12TPC15M
6.3 105
105
85
TPC
85
105
6.3 105
8.0 105 150 7.3 4.3 1.9 D2
68 7.3 4.3 1.9 D2
105 10.0 105 100 7.3 4.3 1.9 D2
22 3.5 2.8 1.1 B1
8.0
105 10.0 105
10
85 10.0 105
85 10.0 105
10 3.5 2.8 1.1 B1
15 3.5 2.8 1.1 B1
12.5
800
18.8
1 Ripple current (100 kHz/ +45 °C ), 2 ESR (100 kHz/+20 °C) 3 tan d (120 Hz/+20 °C) 4 After 5 minutes
✽
✽
✽
✽
Please refer to each page in this catarog for “Reflow conditions” and “Taping specifications”.
◆
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
