5L60 DO-201AD
Trench MOS Barrier Schottky Rectifier
Features
• Advanced trench technology
• Low forward voltage drop
• Low power losses
DO-201AD
5L60
• High efficiency operation
• Lead Free Finish, RoHS Compliant
Applications
• DC/DC Converters
• AC/DC Adaptors
Cathode
Anode
Maximum ratings and electrical characteristics (TJ = 25°C unless otherwise noted)
Parameter
Symbol
VRRM
Limit
60
Unit
V
Maximum repetitive peak reverse voltage
Maximum average forward rectified current
Peak forward surge current 8.3 ms single half
sine-wave superimposed on rated load per diode
Operating junction and storage temperature range
Typical thermal resistance per diode
5
A
IF(AV)
IFSM
TJ, TSTG
RƟJC
150
-40 to +150
20
A
°C
°C/W
(Mounted on FR-4 PCB)
TYP.
0.34
0.27
0.50
0.42
MAX.
IF=1A
TJ=25°C
TJ=125°C
TJ=25°C
TJ=125°C
TJ=25°C
-
IF=1A
IF=5A
IF=5A
VF(1)
IR(2)
-
V
Instantaneous forward voltage
-
-
Instantaneous reverse current per diode
at rated reverse voltage
Notes:
0.2
50
mA
mA
-
-
TJ=125°C
(1) Pulse test: 300 μs pulse width, 1 % duty cycle
(2) Pulse test: Pulse width ≦ 40 ms
