Part Number:
Status:
0982980005
Active
MOX Products
Overview:
Description:
2.54mm Pitch MOX Receptacle Housing, 6 Circuits, Breakable, Dual Row, Gray
Documents:
Drawing (PDF)
Packaging Specification PK-98298-001 (PDF)
Application Specification AS-98298-001-001 (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
Application
Comments
Overview
Product Name
UPC
Series image - Reference only
EU ELV
Crimp Housings
98298
Power, Wire-to-Board
2x3 Circuits
MOX Products
MOX
Compliant
EU RoHS
China RoHS
Compliant
822348723836
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Not Relevant
Need more information on product
environmental compliance?
Physical
Circuits (maximum)
Color - Resin
6
Gray
Receptacle
No
None
Gender
Glow-Wire Capable
Keying to Mating Part
Lock to Mating Part
Material - Resin
Yes
Polyester
2.499/g
2
Bag
No
Net Weight
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Stackable
2.54mm
2.54mm
Yes
China ROHS
ELV
RoHS Phthalates
Not Relevant
Compliant
Not Contained
No
Temperature Range - Operating
-40°C to +105°C
Electrical
Current - Maximum per Contact
Search Parts in this Series
98298 Series
6.0A
N/A
Solder Process Data
Lead-freeProcess Capability
Mates With
Please Contact Molex for Details
Material Info
Use With
98658 MOX Crimp Terminal
Reference - Drawing Numbers
Application Specification
Packaging Specification
Sales Drawing
AS-98298-001-001
PK-98298-001
SD-98298-002, SD-98298-003
