100
Feet
Part No.
QSQS-HOS-100ft
Quick-test 6900 psi hose, S.S. hose ends, 100 ft (30.1 m) long (with hose reel)
Microbore hoses that provide a very quick, low volume, high pressure way of connecting
to any pressure instrumentation, hand pump, calibration source or device under test
Features
•
•
•
•
•
•
•
•
•
Low volume reduces the pumping effort or compressed gas usage in pressure calibration
No thread sealant required – connect to adapters without wrenches, thread sealant or thread tape
Bubble tight connections to 6900 psi (475 bar) with no moving parts reduces maintenance to almost zero
Hose is hard to break and very flexible
Adapt from hose to virtually any device under test with only one connection
Silver color dramatically reduces the effect that changing temperature has on pressure stability
A corrosion resistant strain-relief on each hose end reduces wear and dramatically increases hose life
Hose is pin-pricked for use in Natural Gas applications
Made in U.S.A.
Specifications
Length
100 ft
Pressure Range
Burst Pressure
End 1
0 to 6900 psi (0 to 475 bar)
27000 psi (1,860 bar)
Female Quick-test, stainless steel
End 2
Female Quick-test, stainless steel
Temperature range
Outer Diameter
Inner Diameter
Minimum Bend Radius
Color
-40 to 140 °F (-40 to 60 °C)
0.2 in (5.1 mm)
0.08 in (2.0 mm)
1 in (25.4 mm)
Silver
Construction
End materials
Fluid Media
Polyamide core tube, High tensile synthetic fiber and polyamide outer cover
Stainless Steel
Air, Inert Gas, Natural Gas, Petroleum Based Oil, Water
Ralston Instruments Inc. | ralstoninst.com | Toll Free 800-347-6575 | Phone 440-564-1430 | Fax 440-564-1480
