1SS417FN2_R1_00001

型号:

1SS417FN2_R1_00001

品牌:

PANJIT[ PAN JIT INTERNATIONAL INC. ]

页数:

4 页

PDF大小:

147 K

P1SS417FN2
SURFACE MOUNT SCHOTTKY BARRIER
40 V
100 mA
Voltage
Current
Features
0.022(0.55)
0.017(0.45)
0.042(1.05)
0.037(0.95)
Small package
Low forward voltage : VF(3)=0.51V(typ.)
Low reverse current : IR=5A(Max.)
Lead free in compliance with EU RoHS2.0
(2011/65/EU & 2015/865/EU directive)
0.002(0.05)
MAX.
0.013(0.32)
0.008(0.22)
Green molding compound as per IEC61249 Std..(Halogen Free)
Mechanical Data
Case: DFN 2L plastic case
PIN NO.1
IDENTIFICATION
Terminals: Solderable per MIL-STD-750, Method 2026
Approx. Weight: 0.00004 ounces, 0.0011 grams
Marking:7F
MAXIMUM RATINS (TA=25oC)
PARAMETER
SYMBOL
VALUE
UNIT
Maximum (peak) reverse voltage
VRM
VR
45
V
V
Peak reverse voltage
40
200
Maximum (peak) forward current
IFM
mA
mA
A
Average forward current
IO
100
Surge current (10ms)
IFSM
PD
1
Power dissipation
100
mW
oC
Operating junction and storage temperature range
TJ, TSTG
-55 to +125
May 11,2017-REV.01
Page 1
P1SS417FN2
ELECTRICAL CHARACTERISTICS (TA=25oC)
PARAMETER
SYMBOL
UNIT
V
TEST CONDITION
IF=1mA
MIN.
TYP
0.26
0.34
0.51
-
MAX.
VF1
VF2
VF3
IR
-
-
-
-
-
-
Forward voltage
IF=10mA
-
0.62
5
IF=100mA
Reverse current
VR=40V
A
Junction capacitance
CJ
VR=0V, f=1MHz
10
-
pF
0.12
0.1
100
10
1
0.08
0.06
0.04
0.02
0
0
25
50
75
100
125
150
1
10
100
VR, Reverse Bias Voltage (V)
TC, Case Temperature (°C)
Fig.1 Forward Current Derating Curve
Fig.2 Typical Junction Capacitance
1
500
0.1
TJ = 125°C
0.01
TJ = 125°C
50
5
TJ = 75°C
0.001
0.0001
TJ = 75°C
TJ = 25°C
TJ = 25°C
0.00001
0.5
10 20 30 40 50 60 70 80 90 100
0
0.2
0.4
0.6
0.8
1
Percent of Rated Peak Reverse Voltage (%)
VF, Forward Voltage (V)
Fig.4 Typical Forward Characteristics
Fig.3 Typical Reverse Characteristics
May 11,2017-REV.01
Page 2
P1SS417FN2
PART NO PACKING CODE VERSION
Part No Packing Code
1SS417FN2_R1_00001
Package Type
Packing Type
Marking
7F
Version
DFN 2L
8K pcs / 7reel
Halogen free
MOUNTING PAD LAYOUT
Unitinch(mm)
DFN 2L
0.043
(1.10)
0.017
(0.42)
0.010
(0.26)
0.027
(0.68)
May 11,2017-REV.01
Page 3
P1SS417FN2
Disclaimer
Reproducing and modifying information of the document is prohibited without permission from Panjit
International Inc..
Panjit International Inc. reserves the rights to make changes of the content herein the document anytime
without notification. Please refer to our website for the latest document.
Panjit International Inc. disclaims any and all liability arising out of the application or use of any product
including damages incidentally and consequentially occurred.
Panjit International Inc. does not assume any and all implied warranties, including warranties of fitness for
particular purpose, non-infringement and merchantability.
Applications shown on the herein document are examples of standard use and operation. Customers are
responsible in comprehending the suitable use in particular applications. Panjit International Inc. makes no
representation or warranty that such applications will be suitable for the specified use without further testing or
modification.
The products shown herein are not designed and authorized for equipments requiring high level of reliability or
relating to human life and for any applications concerning life-saving or life-sustaining, such as medical
instruments, transportation equipment, aerospace machinery et cetera. Customers using or selling these
products for use in such applications do so at their own risk and agree to fully indemnify Panjit International
Inc. for any damages resulting from such improper use or sale.
Since Panjit uses lot number as the tracking base, please provide the lot number for tracking when
complaining.
May 11,2017-REV.01
Page 4
