Photoelectric sensors
W12-3, Photoelectric proximity sensor, Background suppression
Type
> WTB12-3N1231
> 1041419
Part No.
At a glance
• State of the art technology provides precise background suppression
• Withstands harsh environments
• PinPoint LED technology with highly visible light spot; variants available with IR
LED for highly critical applications
• Rugged die-cast zinc housing, with optional Teflon® coating
• Versatile mounting options due to dovetail mounting - mounting holes and oblong
holes
Illustration may differ
• Flexible sensing ranges and hysteresis settings
• Key lock function, remote teach, quality monitoring
• Diagnostics messages (contamination and short-circuit)
Your benefits
State of the art technology, e.g. OES3 provides precise background suppression
and reliable detection of challenging objects
High immunity to ambient light, optical reflections and crosstalk ensures fewer false
readings and less downtime
PinPoint LED technology provides a highly visible light spot that enables quick and
easy sensor alignment
Highly visible status LEDs simplify sensing distance adjustments and reduce
installation time
A rugged metal housing withstands high-pressure cleaners and cleaning agents,
reducing downtime
Complementary outputs in one housing reduce inventory and procurement costs
IO-Link enables quick remote diagnostics and maintenance (optional)
Easy installation using SICK accessories
Features
Sensor/detection principle:
Dimensions (W x H x D):
Housing design (light emission):
Sensing range max.:
Sensing range:
Photoelectric proximity sensor, Background suppression
15.6 mm x 48.5 mm x 42 mm
Rectangular
20 mm ... 350 mm 1)
20 mm ... 350 mm
Visible red light
Type of light:
