Part Number:
Status:
0982670272
Active
Premo-Flex Cable Jumpers
Overview:
Description:
1.00mm Pitch Premo-Flex FFC Jumper, Opposite Side Contacts (Type D), 12 Circuits,
0.076m Cable Length, Tin(Sn) Plating
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Product Specification PS-98267-001-001 (PDF)
Packaging Specification PK-98267-001-001 (PDF)
Product Literature (PDF)
Series image - Reference only
EU ELV
General
Product Family
Series
Cable
98267
Not Relevant
Comments
Crimp Quality Equipment
Overview
Product Literature Order No
Product Name
UPC
Contacts on opposite sides, Type D
Yes
Premo-Flex Cable Jumpers
987650-6631
Premo-Flex FFC Jumper
756054771129
EU RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
China RoHS
Physical
Cable Length
Halogen-Free
Status
0.076m
Circuits (Loaded)
Circuits (maximum)
Net Weight
12
12
0.699/g
Bag
Not Low-Halogen
Need more information on product
environmental compliance?
Packaging Type
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
Pitch - Termination Interface
Temperature Range - Operating
Wire Size AWG
1.00mm
-40°C to +105°C
N/A
Wire/Cable Type
Flat Flex Cable
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Electrical
Current - Maximum per Contact
Voltage - Maximum
1.2A
60V AC
Material Info
Search Parts in this Series
98267 Series
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
PK-98267-001-001
PS-98267-001-001
SD-98267-001
Use With
52207 , 52271 , 52852 , 52793 , 52808
, 52610 , 52807 , 52030 , 52806 <br><a
href="http://www.molex.com/product/ffc">
Molex FFC – FPC connector</a>. Be sure to
match like plating.
