Applications
OV493
¬ Surround view system
¬ Camera Monitoring System (CMS)
¬ e-Mirror
Ordering Information
¬
OV00493-B69G-1A
(lead-free, 169-pin BGA,
packed in tray)
¬ OV00493-B69G-TA
(lead-free, 169-pin BGA,
packed in tape and reel)
Product Features
¬ advanced 100Mp/s throughput ISP
for high quality image capturing and
video streaming
¬ supports four-wire or two-wire serial
interface to retrieve stored firmware
from external memory devices,
such as EEPROM
¬ local and global tone mapping support
¬ up to 3-capture HDR combination
¬ on-chip PLL to generate internal clocks
¬ on-chip voltage regulator 1.8V to 1.1V
Product Specifications
¬ simultaneous output of fully
processed YUV for display-based
applications and RAW for
¬
power supply:
¬
temperature range:
¬ brown-out detection circuit
and output flag
- core: 1.1V ±5%
- operating: -40°C to +105°C
ambient temperature and
-40°C to +125°C junction
temperature
- I/O: 1.8V ±5% or 3.3V ±5%
machine vision applications
¬ supports 2x2 lane MIPI RX/TX
and 1x4 lane MIPI RX/TX
¬
power requirements: 256 mW,
¬ embedded information including
frame counter, temperature, and
register data for each image to
enable critical automotive safety
applications
measured at 1392x976 @ 30 fps,
12-bit plus 12-bit input from OV9716
via MIPI interface and 1392x976
YUV422 output via MIPI interface
¬
package dimensions: 7 mm x 7 mm
¬ supports 12-bit DVP input,
shared with MIPI RX
¬ supports 12-bit DVP output,
shared with MIPI TX
¬ auto white balance (AWB)
¬ automatic exposure control (AEC) /
automatic gain control (AGC)
¬ supports 24-bit DVP output,
shared with BT1120 output
¬ supports statistics data of up to
four user programmable ROIs
¬ embedded 32-bit RISC processor
for high performance and flexibility
¬ SCCB master/slave interface for
sensor and ASIC configuration
¬ supports 1K bits of one-time
programmable memory (OTP)
¬ JTAG boundary scan
Advanced Architecture Example
camera modules
ECU module
30 fps RAW
MIPI CSI-2 / DVP
2x [RAW @ 30 fps]
2x 2 lane MIPI CSI-2
output
1x 4 lane MIPI CSI-2
LVDS
I2C
OV9716
[1]
OV493
[1]
SER
I2C
I2C
I2C
30 fps RAW
MIPI CSI-2 / DVP
LVDS
I2C
OV9716
SER
[2]
I2C
GPU /
DSP /
MCU /
FPGA
video
quad
DES
SPI
flash
30 fps RAW
MIPI CSI-2 / DVP
LVDS
I2C
OV9716
[3]
SER
I2C
30 fps RAW
MIPI CSI-2 / DVP
2x [RAW @ 30 fps]
2x 2 lane MIPI CSI-2
output
1x 4 lane MIPI CSI-2
LVDS
I2C
OV9716
[4]
OV493
[2]
SER
I2C
I2C
I2C
