SMD Zener Diode
CZRQC52C2V4-HF
Voltage 2.4 Volts
Power 125 mW
RoHS Device
Halogen Free
0402C/SOD-923F
Features
0.041(1.05)
0.037(0.95)
- Designed for mounting on small surface.
- Extremely thin/leadless package.
0.026(0.65)
0.022(0.55)
Mechanical data
- Case: 0402C/SOD-923F standard package.
Molded plastic.
0.022(0.55)
0.018(0.45)
- Terminals: Matte tin plated, solderable per
MIL-STD-750,method 2026.
0.010(0.25)
0.008(0.21)
0.001(0.02)
Max.
- Polarity: Indicated by cathode band.
- Weight: 0.001 grams(approx.).
Circuit diagram
0.020(0.50)
0.018(0.46)
Dimensions in inches and (millimeter)
Maximum Rating (at TA=25°C unless otherwise noted)
Symbol
Parameter
Value
Unit
Maximum Forward Voltage Drop at IF = 10 mA
Maximum Power Dissipation at 25 °C
Forward current , surge peak
0.9
VF
PD
V
mW
125
8.3 ms single half sine-wave superimposed
IFSM
2.0
A
on rate load( JEDEC method )
Operating Temperature Range
Storage Temperature Range
TJ
-55 to +125
-55 to +125
°C
°C
Tstg
Electrical Characteristics(at TA=25°C unless otherwise noted)
Rising
operating
Resistance
Operating
resistance
Reverse
current
Zener Voltage
Marking
Part Number
Code
VZ(V)
ZZT(Ohm)
IZ
ZZK(Ohm)
IZ
IR(uA)
VR
IZ
Typ
Min
Max
Max
Max
Max
(mA)
(mA)
(mA)
(V)
CZRQC52C2V4-HF
Z2
2.28
2.40
2.52
5
85
5
600
1
100
1
Company reserves the right to improve product design , functions and reliability without notice.
REV:A
Page 1
QW-G2014
Comchip Technology CO., LTD.
