NEW! DZ24 & DZ2W Series
Clip Type, Surface Mount Zener Diodes
High Power Dissipation With Wider Thermal Design Margins
PanasonicꢀElectronicꢀComponents,ꢀaꢀworldwideꢀleaderꢀinꢀSemiconductorꢀProducts,ꢀisꢀpleasedꢀ
toꢀannounceꢀtwoꢀnewꢀSeriesꢀadditionsꢀtoꢀourꢀalreadyꢀsuccessfulꢀlineꢀofꢀZenerꢀDiodes.ꢀꢀTheꢀ
NEW DZ24 and DZ2W Seriesꢀprovideꢀsignificantlyꢀsmallerꢀsurfaceꢀmountꢀpackagesꢀandꢀofferꢀ
highꢀpowerꢀdissipationꢀandꢀwiderꢀthermalꢀdesignꢀmargins.ꢀꢀTheꢀNEW DZ24 Seriesꢀ1WꢀTypeꢀ
providesꢀaꢀzenerꢀvoltageꢀrangeꢀofꢀ2.4Vꢀtoꢀ51VꢀwhileꢀtheꢀNEW DZ2W Seriesꢀ2WꢀTypeꢀfeaturesꢀ
aꢀzenerꢀvoltageꢀrangeꢀofꢀ4.7Vꢀtoꢀ51V
Features:
Part Number Information:
DZ24 Series
•ꢀZenerꢀVoltageꢀTolerance:ꢀ 55
•ꢀZenerꢀVoltage:ꢀDZ24ꢀSeries:ꢀ4.7Vꢀtoꢀ51Vꢀꢀ
ꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀꢀDZ2WꢀSeries:ꢀ2.4Vꢀtoꢀ51V
•ꢀSignificantlyꢀReducedꢀMountingꢀAreaꢀ
WhenꢀComparedꢀWithꢀConventionalꢀ1Wꢀ
Typesꢀ-ꢀDZ2WꢀSeries
1
2
3
4
5
6
7
8
9
10
D Z 2 4 0 2 4 0 0 L
Product Code
Package
Zener Voltage
Taping
VZ Rank
Terminal Count
Specification
•ꢀHalogenꢀFreeꢀPackage
•ꢀRoHSꢀDirectiveꢀCompliant
Part Number Information:
DZ2W Series
Benefits:
1
2
3
4
5
6
7
8
9
10
•ꢀWiderꢀThermalꢀDesignꢀMargin
•ꢀCostꢀsavingꢀHeatꢀSinkꢀAlternative
•ꢀSurfaceꢀMountableꢀPackageꢀ
D Z 2 W 0 2 4 0 0
L
Taping
Product Code
Package
Zener Voltage
VZ Rank
Specification
Terminal Count
Industries:ꢀꢀꢀꢀꢀꢀ
•ꢀIndustrialꢀMachinery
•ꢀMedical
Additional Information:
Forꢀdetailedꢀspecificationꢀ
informationꢀonꢀtheꢀNEWꢀ
DZ24ꢀ&ꢀDZ2WꢀSeries,ꢀvisit:ꢀ
panasonic.com/industrial/
includes/zip/DZ24_DZ2W_
DataSheet.zipꢀtoday!
•ꢀDataꢀManagementꢀEquipmentꢀ(Servers)
•ꢀLighting
Applications:ꢀꢀꢀꢀꢀꢀ
•ꢀPowerꢀSupplies
•ꢀBatteryꢀChargedꢀCircuits
•ꢀHighꢀPowerꢀLEDꢀLamps
•ꢀAudio
Website: www.panasonic.com/industrial/electronic-components
