CERAMIC CAPACITORS
Spec Sheet
LW Reversal Decoupling MLCC for Automotive / Industrial Applications (LWDC(TM))
JWK107BJ475MVHT
Features
Item Summary
6.3V, X5R, 4.7μF, ±20%, 0306
Lifecycle Stage
Mass Production
AEC-Q200 qualified
Standard packaging quantity (minimum)
Taping Embossed 4000pcs
Products characteristics table
CaseSize (EIA/JIS)
External Dimensions
L
0.8mm ±0.10
1.6mm ±0.10
0.5mm ±0.05
0.25mm ±0.15
0306/1608
6.3V
W
T
e
Rated Voltage (max)
Capacitance
4.7μF
Capacitance Tolerance
Resistance
±20%
100 MΩ・μF min.
10%MAX
X5R/-
Dielectric Loss Tangent
Temperature Characteristics (EIA/JIS)
Temperature Range (EIA/JIS)
Capacitance Change (EIA/JIS)
RoHS Compliance
-55 to +85℃/-
±15/-%
Yes
Halogen Free
Yes
Soldering Method
Reflow
2015.02.05
The data is reference only. Electrical characteristics vary depending on environment or measurement condition.
TAIYO YUDEN reserves the right to make change to the Date at any time without notice.
Before making final selection, please check product specification.
