Microwave Components/Modules > Microchip Transformer (Balun) > Wire Wound Type
2
Data Sheet
Continued from the preceding page.
Insertion Loss Characteristics
CMRR Characteristics
c
c
DXW21BN7511T
DXW21BN7511T
0
1
2
3
4
5
6
45
40
35
30
25
20
50
100
1000
2000
50
100
1000
2000
Frequency (MHz)
Frequency (MHz)
Caution/Notice
c !
Caution (Rating)
Notice
!
Do not use products beyond the rated current and rated
voltage as this may create excessive heat and
deteriorate the insulation resistance.
Solderability of Tin plating termination chip might be
deteriorated when low temperature soldering profile
where peak solder temperature is below the Tin melting
point is used. Please confirm the solderability of Tin
plating termination chip before use.
