MYPMA01218RCF-CAB
Non-isolated type
Note prior to use
Functional Specifications
If you apply high static electricity, voltage higher than rated voltage or
reverse voltage to the product, it may cause defects in the products or
degrade the reliability.
Please avoid the following items:
1. Over rating power supply, reverse power supply or not-enough
connection of input voltage and 0V(DC)line
Please contact Murata Sales before using this product for the
applications listed below. These are applications that require very high
reliability of prevention of defects which might directly cause damage
to third party’s life, body, or property.
1. Aircraft equipment
2. Aerospace equipment
2. Electrostatic discharge by production line and/or operator
3. Electrified product by electrostatic induction
3. Undersea equipment
4. Power plant control equipment
5. Medical equipment
6. Transportation equipment (cars, buses, trucks, trains, ships, etc.)
7. Traffic signal equipment
8. Disaster prevention /crime prevention equipment
9. Data-processing equipment
10. Application of similar complexity and /or reliability
• Do not subject product to excessive mechanical shock. If you drop
the product on the floor it might cause a crack to the core of inductors
and monolithic ceramic capacitors.
• Also please pay attention to handling; the mounted parts can be
dislodged if subjected to excessive force.
• Input and output wiring cords should have slack so that they do not
exert stress to the input/output connectors of the product. Subjecting
the connectors to sustained stress may damage the product.
Storage
Please store this product in an environment where the
temperature/humidity is stable in the range 0 to 40°C/10 to 75%RH
and no direct sunlight. Use the product within 6 months after delivery.
Please avoid storage conditions where humidity and temperature
change rapidly, as that may cause condensation on the product, which
might degrade the quality of the product.
This product may rust after a long time (more than 1 year) storage.
Please do not store the product environments that are dusty, in direct
exposure to sea breeze, or in an atmosphere containing corrosive gas
(Cl2, NH3, SO2, NOX and so on).
Assembly
Assemble the frame by using M5 screws, with a torque of 1.51Nm
[reference only]
Transportation
If you transport the product, please pack it so that the package will not
be damaged by mechanical vibration or mechanical shock, and please
educate and guide the carrier to prevent rough handling.
If you transport the products overseas (in particular, by sea), it is
expected that the transportation environment will be the worst, so
please pack the products in a package that is mechanically strong,
vibration-resistant, and humidity-resistant. The packaging of the
products that Murata sells in Japan may not be suitable overseas
transport. Please consult Murata Sales if you plan to use the standard
Murata packaging of the products for transport to overseas.
Operational environment and operational conditions
Operational environment
This product is not chemical-proof or rust-proof.
In order to prevent this product from leakage of electricity and/or
abnormal temperature increase, do not use the product under the
following circumstances:
(1) in an atmosphere containing corrosive gas (Cl2, NH3, SO2, NOX
and so on).
(2) in a dusty place.
(3) in a place exposed to direct sunlight.
(4) in such a place where water splashes or in such a humid place
where water condenses.
Note
1. Please make sure that the product has been evaluated and
confirmed against your specifications when it is mounted to your
product.
2. All the items and parameters in this product specification have been
prescribed on the premise that our product is used for the purpose,
under the conditions and in the environment agreed upon between
you and us. You are requested not to use our product deviating from
such agreement.
3. We consider it not appropriate to include other terms and conditions
for transaction warranty in product specifications, drawings or other
technical documents. Therefore, if your technical documents as
above include such terms and conditions as warranty clause, product
liability clause, or intellectual property infringement liability clause, we
will not be able to accept such terms and conditions unless they are
based on the governmental regulation or they are stated in a
separate contract agreement.
(5) in a place exposed to sea breeze.
(6) in any other places similar to the above (1)through (5).
Operational conditions
Please use the product within specified values (power supply,
temperature, input, output and load condition etc.). Input voltage drops
for line impedance, so please make sure that input voltage is within in
specified values.
If the product is used over the specified values, it may damage the
product, reduce the quality, and even if the products can endure the
condition for short time, it may cause degradation of the reliability.
This information is subject to change without notice. Please contact our sales or product engineers to confirm the latest before
purchasing.
www.murata.co.jp
P6/6
March 2, 2016
