1T362
Silicon Variable Capacitance Diode
Description
M-235
The 1T362 is a variable capacitance diode
designed for electronic tuning of TV tuners, and the
super miniature package allows the tuner
miniaturization.
Features
• Super miniature package
• Low series resistance 0.65 Ω Max. (f=470 MHz)
• Large capacitance ratio 6.5
Typ. (C2/C25)
Absolute Maximum Ratings (Ta=25 °C)
• Small leakage current 10 nA Max. (VR=28 V)
• Maximum capacitance deviation
• Reverse voltage
VR
30
35
V
V
• Peak reverse voltage
VRM
3 %
Max.
(RL≥10 kΩ)
85 °C
Tstg –55 to +150 °C
• Operating temperature Topr
• Storage temperature
Applications
Electronic tuning for TV and CATV
Structure
Silicon epitaxial planar type diode
Electrical Characteristics
(Ta=25 °C)
Item
Symbol
Conditions
Min.
Typ.
Max.
10
Unit
nA
pF
Reverse current
IR
C2
VR=28 V
VR=2 V, f=1 MHz
VR=25 V, f=1 MHz
14.01 15.00 16.33
Diode capacitance
C25
2.10
2.27
6.5
2.39
0.65
3
pF
Capacitance ratio
Series resistance
Maximum-capacitance
deviation in the
C2/C25 f=1 MHz
rs
CD=14 pF, f=470 MHz
0.57
Ω
∆C
VR=2 to 25 V, f=1 MHz
%
same ranking
