1T368
Variable Capacitance Diode
Description
M-235
The 1T368 is a variable capacitance diode
contained in super miniature package, designed for
wide band CATV.
Features
• Super miniature package
• Small series resistance
• High capacitance ratio
rs=0.75 Ω
(Max.)
C2/C25=11.5 (Typ.)
• Capacitance deviation in a matching group
2.0 % (Max.)
Absolute Maximum Ratings (Ta=25 °C)
• Reverse voltage
• Operating temperature Topr
• Storage temperature
VR
30
V
–20 to +75
°C
Applications
Tstg –65 to +150 °C
Electronic tuning of wide band CATV
Structure
Silicon epitaxial planar type diode
Electrical Characteristics
(Ta=25 °C)
Item
Symbol
IR
Conditions
Min.
Typ.
11.5
Max.
10
Unit
nA
pF
Reverse current
VR=28 V
C2
VR=2 V, f=1 MHz
VR=25 V, f=1 MHz
29.40
2.53
11.0
34.30
2.93
Diode capacitance
C25
pF
Capacitance ratio
Series resistance
C2/C25
rs
CD=14 pF, f=470 MHz
VR=2 to 25 V
0.75
2.0
Ω
Capacitance deviation in a
matching group
∆C
%
