1T403
Variable Capacitance Diode
Description
M-290
The 1T403 is a variable capacitance diode
designed for electronic tuning of VHF TV tuners and
CATV tuners using a super-small-miniature flat
package (SSVC).
Features
• Super-small-miniature flat package
• Low series resistance: 0.8 Ω Max. (f=470 MHz)
• Large capacitance ratio: 15.0 Typ.
(C1/C28)
Absolute Maximum Ratings (Ta=25 °C)
• Small leakage current: 10 nA Max. (VR=28 V)
• Capacitance deviation in a matching group:
within 2 %
• Reverse voltage
VR
30
35
V
V
• Peak reverse voltage
VRM
(RL≥10 kΩ)
–20 to +75 °C
Tstg –65 to +150 °C
• Operating temperature Topr
• Storage temperature
Applications
Electronic tuning of TV and CATV tuners
Structure
Silicon epitaxial planar type diode
Electrical Characteristics
(Ta=25 °C)
Item
Symbol
Conditions
VR=28 V
Min.
Typ.
Max.
Unit
Reverse current
Diode capacitance
IR
C1
10
nA
pF
pF
VR=1 V, f=1 MHz
VR=28 V, f=1 MHz
34.61
2.321
13.5
42.31
2.714
C28
C1/C28
rs
Capacitance ratio
Series resistance
Capacitance
15.0
0.75
CD=14 pF, f=470 MHz
VR=1 to 28 V, f=1 MHz
0.80
2
Ω
deviation in a
∆C
%
matching group
