SST-10-B-B130

型号：

SST-10-B-B130

品牌：

LUMINUS[ Luminus ]

页数：

12 页

PDF大小：

2219 K

下载PDF手册

SST-10-Blue Product Datasheet

SST-10-B

Blue LED

Features:

• High Power Blue LED with Peak Wavelength of 450nm

• Wall-Plug Eﬃciency: typ. 57% @350mA

• 90 or 130° viewing angle at 50% Iv

• Low Thermal Resistance

Table of Contents

SST-10 Binning Structure . . .2

Product Shipping & Labeling

Information. . . . . . . . . . . . . . . .3

• Built-in ESD Protection

• RoHS and REACh compliant

Optical and Electrical

Characteristics . . . . . . . . . . . . .4

B130 - Mech. Dimensions . . .6

B130 - Tape and Reel . . . . . . .7

B90 - Mech. Dimensions . . . .8

B90 - Tape and Reel. . . . . . . . .9

Soldering Proﬁle . . . . . . . . . 10

Precautions for Use. . . . . . . 11

History of Changes . . . . . . . 12

Applications

• Horticulture / Growlights

• Accent and eﬀect lighting

• Architectural lighting

• Remote-phosphor ﬁxtures

• Stage lighting

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

SST-10 Binning Structure

SST-10 Blue LEDs are tested for luminous ﬂux and chromaticity at a drive current of 350mA - 20ms single pulse and placed into one of the

following luminous ﬂux (FF) and chromaticity (WW) bins:

Flux Bins - Test condition=350mA, 25ꢀC, 20ms pulse

Flux Bin (FF)

Minimum Flux (mW)

Maximum Flux (mW)

510

550

590

630

550

590

630

670

Wavelength Bins - Test condition=350mA, 25ꢀC, 20ms pulse

Chromaticity Bin (WW)

Minimum Wavelength (nm)

Maximum Wavelength (nm)

440

445

450

455

445

450

455

460

*Note: Luminus maintains a +/- 6% tolerance on ﬂux measurements.

Ordering Information

Products

SST-10-B-B90

SST-10-B-B130

Ordering Part Number

SST-10-B-B90-xx123

SST-10-B-B130-xx123

Description

High Power 1-mm²Blue LED in a 3535 surface mount package and a 90-de-

gree lens

High Power 1-mm²Blue LED in a 3535 surface mount package and a

130-degree lens

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

Part Number Nomenclature

SST

<A>

<B###>

<FF###>

Product Family

LED Emission Area

Color

Package Conﬁguration

Bin kit

Flux and Chromaticity bin kit

code - See available ordering

codes below

SST: Surface Mount

Package

<A>: Color

B = Blue

B90: 90-degree lens

B130: 130-degree lens

10: 1.0 mm²

SST-10 Bin Kit Order Codes

The following table describes the bin kit ordering codes available for the SST-10 Blue LEDs. Each bin kit speciﬁes a minimum ﬂux as well

as speciﬁc chromaticity bins allowed. Please note that within each kit a maximum ﬂux is not speciﬁed and as a result Luminus may ship

any part meeting or exceeding the minimum ﬂux speciﬁcation. Shipments will always meet the listed chromaticity bins. For information

on ordering bin kits not listed below, please contact Luminus.

SST-10 Blue Bin Kit Order Codes

Luminous Flux

Color

Blue

Chromaticity Bins

Kit Number

N450

Bin Kit Flux

Code

Min. Flux

510

B2,B3,B4,B5

Product Shipping & Labeling Information

All SST-10 products are packaged and labeled with their respective bin as outlined in the tables on pages 2 & 3. Each reel will only

contain one bin.

SST-10 Blue

SST

BXXX

FFWW

Product Family

LED Emission Area

Color

Package Conﬁguration

Bin kit

SST: Surface Mount

Package

B90: 90-degree lens

B130: 130-degree lens

Flux and Chromaticity bin kit

code as outlined above

10: 1.0 mm²

Color

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

(Part #) Product Datasheet

Optical and Electrical Characteristics

Optical and Electrical Characteristics at 350mA¹

Parameter

Forward Current²

Symbol

Minimum

Typical

350

Maximum

Unit

I_f

Φ_r

1,500

Output Power

600

Forward Voltage

Wall-Plug Eﬃciency

Viewing Angle

Peak Wavelength

V_f

2.7

3.0

3.4

WPE

2 Ø_1/2

λ_P

90 or 130

450

degrees

440

460

FWHM

Dλ_1/2

Thermal Resistance (Electrical)

R_TH

5.3

°C/W

Absolute Maximum Ratings²

Parameter

Symbol

Rating

Unit

Forward Current^3,4

Power Dissipation

Reverse Voltage

1.5

TsTg

5.0

Storage Temperature

Junction Temperature^3,4

Soldering Temperature

ESD Sensitivity (HBM)

-40~100

°C

115 ºC

Tsld

JEDEC 020, 260 ºC

6000

Note 1: Ratings are based on operation at a constant junction temperature of T_j= 25ºC.

Note 2: To prevent damage, please refer to operating conditions and derating curves for appropriate maximum operating conditions

Note 3: Maximum operating case temperature combined with maximum drive current deﬁnes the total maximum operating condition for the device. To

prevent damage, please follow derating curves for all operating conditions.

Note 4: Luminus SST-10-Blue LEDs are designed for operation up to an absolute maximum forward drive current as speciﬁed above. Product lifetime data

is speciﬁed at typical forward drive currents. Sustained operation at absolute maximum currents will result in a reduction of device lifetime compared

to typical forward drive currents. Actual device lifetimes will also depend on junction temperature. Refer to the current vs. junction temperature

derating curves for further information. In pulsed operation, rise time from 10-90% of forward current should be larger than 0.5 microseconds.

Note 5: Caution must be taken not to stare at the light emitted from these LEDs. Under special circumstances, the high intensity could damage the eye.

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

(Part #) Product Datasheet

Optical and Electrical Characteristics

Relative Output Flux vs. Forward Current

Relative Output Flux vs. Junction Temperature

Typical Polar Radiation Plot - B130

Forward Current vs. Forward Voltage

Typical Spectra

Typical Polar Radiation Plot - B90

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

Mechanical Dimensions - B130 Package

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

Tape and Reel - B130 Package

4.00±0.10

.157±.004

0.10

0.00

.004

.000

2.00±0.10

.079±.004

3.80

0.10

1.50

0.00

.004

.150

1.75±0.10

.069±.004

CATHODE SIDE

.059

.000

0.10

0.00

4.18

.004

.000

5.0°

.165

12.00±0.20

.472±.008

1.70±0.10

.067±.004

5.50±0.05

.217±.002

0.25±0.05

SECTION A-A

8.00±0.10

.315±.004

ANODE SIDE

0.10

3.80

0.00

.004

.000

.150

0.10

0.00

4.18

.004

.000

NOTES:

.165

1. FINAL TAPE AND REEL PACKAGING MUST MEET THE

REQUIREMENTS OF JEDEC-STD-033, LEVEL 2A.

0.10

0.00

.004

.000

2.20

2. LEAVE 304.8mm [12.00 in] OF TAPE EMPTY FOR LEAD IN

(38 EMPTY POCKETS).

5.0°

.087

3. LEAVE 457.2mm [18.00 in] OF TAPE EMPTY FOR TRAILER

(57 EMPTY POCKETS).

SECTION B-B

4. MUST COMPLY TO EIA-481-C-2003

12.4

.488

UNREELING DIRECTION

178

21.3

.839

2.00

.079

.512

16.0

.630

120°

DETAIL C

UNREELING DIRECTION

TOP VIEW

DETAIL D

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

Mechanical Dimensions - B90 Package

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

Tape and Reel - B90 Package

4.00±0.05

.157±.002

2.00±0.10

.079±.004

0.10

0.00

.004

.000

1.50

1.75±0.10

.069±.004

CATHODE SIDE

.059

3.60±0.10

.142±.004

7.0°

12.00±0.20

.472±.008

1.50±0.10

.059±.004

5.50±0.05

.217±.002

0.25±0.05

8.00±0.10

.315±.004

ANODE SIDE

SECTION A-A

3.67±0.10

.144±.004

NOTES:

1. FINAL TAPE AND REEL PACKAGING MUST MEET THE

REQUIREMENTS OF JEDEC-STD-033, LEVEL 2A.

2. LEAVE 304.8mm [12.00 in] OF TAPE EMPTY FOR LEAD IN

(38 EMPTY POCKETS).

2.48±0.10

.098±.004

7.0°

3. LEAVE 457.2mm [18.00 in] OF TAPE EMPTY FOR TRAILER

(57 EMPTY POCKETS).

SECTION B-B

4. MUST COMPLY TO EIA-481-C-2003

3.8

UNREELING DIRECTION

560

22.0

3.0

UNREELING DIRECTION

TOP VIEW

DETAIL D

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

Soldering Proﬁle

Proﬁle Feature

Preheat & Soak

Temperature min (Tsmin)

Temperature max (Tsmax)

Time (Tsmin to Tsmax) (ts)

Sn-Pb Eutectic Assembly

Pb-Free Assembly

100 °C

150 °C

60-120 seconds

150 °C

200 °C

60-120 seconds

Average ramp-up rate (Tsmax to Tp)

3 °C/second max

Liquidous temperature (TL)

Time at liquidous (tL)

183 °C

60-150 seconds

217 °C

60-150 seconds

Peak package body temperature (Tp)*

Classiﬁcation temperature (Tc)

230 °C ~235 °C

235 °C

255 °C ~260 °C

260 °C

Time (tp) within 5 °C of the speciﬁed

classiﬁcation temperature (Tc)

20 seconds

30 seconds

Average ramp-down rate (Tp to Tsmax)

Time 25 °C to peak temperature

6 °C/second max

6 minutes max

6 °C/second max

8 minutes max

* Tolerance for peak proﬁle temperature(Tp) is deﬁned as a supplier minimum and a user maximum.

** Tolerance for time at peak proﬁle temperature(tp) is deﬁned as asupplier minimum and a user maximum.

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

Precautions for Use

Storage:

1. Before opening the package

The LEDs should be kept at a temperature lower than 40° C and relative humidity lower than 90%. The LEDs should be used within a

year. When storing the LEDs, moisture proof package with absorbent material (silica gel) is recommended.

2. After opening the package

The LEDs should be kept at temperature lower than 30° C and relative humidity lower than 60%. The LEDs should be soldered within

168 hours (7days) after opening the moisture proof package.

If unused LEDs remain, they should be stored in moisture proof packages, such as sealed containers with moisture proof package

within absorbent material (silica gel). It is also recommended to return the unused LEDs to the original moisture proof package and to

seal the moisture proof package again.

If the moisture absorbent material (silica gel) vapors or expires the expiration date, baking treatment should be performed by using

the following conditions : 60 °C for 20 hours.

The LEDs electrode and leadframe comprise a silver plated copper alloy. The silver surface may be aﬀected by environments. Please

avoid conditions which may cause the LEDs to corrode or discolore. The corrosion or discoloration might lower solderability or aﬀect

optical characteristics.

Please avoid rapid transition in ambient temperature, especially in high humidity environments where condensation can occur.

Static Electricity:

1. The products are sensitive to static electricity, and care should be taken when handling them.

2. Static electricity or surge voltage will damage the LEDs. It is recommended to wear a anti-electrostatic wristband or anti-electrostat-

ic gloves when handling the LEDs.

3. All devices, equipment and machinery must be properly grounded. It is recommended that measures be taken against surge volt-

age to the equipment that mounts the LEDs.

Luminus Devices, Inc. • T 408.708.7000

1145 Sonora Court

•

www.luminus.com

PDS-002735 Rev 05

•

Sunnyvale, CA 94086

SST-10-Blue Product Datasheet

History of Changes

Rev

Description of Change

09/14/2015

10/13/2015

04/15/2016

06/24/2016

04/03/2017

Initial Release - Preliminary Speciﬁcations

Updated solder pad layout and added 80-degree lens option

Updated binning and angular distribution data. Added 90-degree tape & reel

Updated pictures on front page

Updated title in “Relative Output Flux vs. Junction Temperature”graph and address.

Luminus Devices, Inc. • T 408.708.7000

•

www.luminus.com

PDS-002735 Rev 05

1145 Sonora Court

• Sunnyvale, CA 94086

厂商	型号	描述	页数
TE	SST	工业级离散插件[ Industrial Grade Discrete Plug-in ]	1 页
SAMTEC	SST-0101-G-10-L	[ IC Socket, SIP1, 1 Contact(s), ]	1 页
SAMTEC	SST-0101-G-11-L	[ IC Socket, SIP1, 1 Contact(s), ]	1 页
SAMTEC	SST-0101-G-12-L	[ IC Socket, SIP1, 1 Contact(s), ]	1 页
SAMTEC	SST-0101-G-15-L	[ IC Socket, SIP1, 1 Contact(s), ]	1 页
SAMTEC	SST-0101-G-18-L	[ IC Socket, SIP1, 1 Contact(s), ]	1 页
SAMTEC	SST-0101-G-22-L	[ IC Socket, SIP1, 1 Contact(s), ]	1 页
SAMTEC	SST-0101-G-23-L	[ IC Socket, SIP1, 1 Contact(s), ]	1 页
SAMTEC	SST-0101-G-32-L	[ IC Socket, SIP1, 1 Contact(s), ]	1 页
SAMTEC	SST-0101-G-34-L	[ IC Socket, SIP1, 1 Contact(s), ]	1 页
